4. Motor controller board

The motor controller board connects to the development board and to the 3-phase inverter board,
see
•
•
•
•
•
•
•
•

Fig. 12. Motor controller board connector locations

4.1. DC-to-DC converter to generate VDD

The controller board has an on-board DC-to-DC step-down buck regulator that will supply power for
the entire controller board, and for development board if selected, see
to-DC regulator is supplied through the VIN connection (J1) from the 3-phase inverter board, which
is discussed in
DC-to-DC converter with internal synchronous switches that provide current for output loads up to
0.6 A.
UM90029
Submit document feedback
User manual
NEVB-MCTRL-100-01-3INV-001-01 motor driver evaluation kit
Fig. 12, it features:
DC-to-DC converter to generate VDD
Gate driver for MOSFETs
Position sensor inputs
Development board or microcontroller board connections
Interface signals to the 3-phase inverter board
Back-emf zero-crossing detection circuit
User motor control inputs
MUX, fault and over-voltage indicator LEDs
J9
J7
J2
JP2
J4
J3
Section 3.3. VIN is routed to the LT8630, which is a current mode PWM step-down
