Reference Qty Value
J5 1 VIN2
J6 1 GND
J7 1 GND
J8 1 VIN1
J9 1 VIN1
J10 1 VIN
J11 1 Signals1
J12 1 Signals2
Q1, Q2, Q3, Q4, 6 PSMN3R9-100YSF
Q5, Q6
R1, R2, R3, R4, 12 10
R9, R10, R11,
R12, R17, R18,
R19, R20
R5, R6, R13, 6 10k
R14, R21, R22
R7, R8, R15, 6 TBD
R16, R23, R24
R25 1 2m-1%-6W
R26 1 200-1%
R27 1 3.9k
R28 1 10k-1%
R29 1 12k-1%
UM90029
Submit document feedback
User manual
Footprint
Connectors:Wurth_7466205R_M5_70A_Top_Mod
Connectors:Wurth_7466205R_M5_70A_Top_Mod
Connector_Custom:KEYSTONE_575-4
Connector_Custom:KEYSTONE_575-4
Connectors:Wurth_7466205R_M5_70A_Top_Mod
Connector_Custom:PinSocket_2x04_P2.54mm
_Horizontal_Clipped_SilkScreen
Connector_Custom:PinSocket_2x07_P2.54mm
_Horizontal_Clipped_SilkScreen
Connector_Custom:PinSocket_2x07_P2.54mm
_Horizontal_Clipped_SilkScreen
Package_TO_SOT_SMD:LFPAK56
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0805_2012Metric_Pad1.20x1.40mm_HandSolder
Resistor_SMD:R_2512_6332Metric_Pad1.40x3.35mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_1206_3216Metric_Pad1.30x1.75mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
All information provided in this document is subject to legal disclaimers.
Rev. 1.0 — 15 April 2024
NEVB-MCTRL-100-01-3INV-001-01 motor driver evaluation kit
Manufacturer Mfg Part No
WURTH 7466205R
ELEKTRONIK
WURTH 7466205R
ELEKTRONIK
KEYSTONE 575-4
KEYSTONE 575-4
WURTH 7466205R
ELEKTRONIK
WURTH 613008243121
ELEKTRONIK
WURTH 613014243121
ELEKTRONIK
WURTH 613014243121
ELEKTRONIK
NEXPERIA PSMN3R9-100YSFX
KAMAYA RMC1/16K10R0FTP
KAMAYA RMC1/16103JTP
VISHAY / DALE WSLF25122L000FEA
YAGEO RT0603FRE10200RL
BOURNS CR1206-FX-3901ELF
KAMAYA RMC1/16103JTP
YAGEO AC0603FR-1012KL
UM90029
DNP
DNP
