Nexperia
Net name
J12
PHASE_W
GATE_WB
CURRENT
NA
BOARD_REF
IOREF
GND
UM90029
Submit document feedback
User manual
NEVB-MCTRL-100-01-3INV-001-01 motor driver evaluation kit
Pin number
Description
1
Switch node or motor phase voltage of phase W
3
Low side gate voltage for phase W
5
Output voltage from high-side current monitor
7, 9
Not used
11
Voltage derived from IOREF that is sensed by development
board
13
IO reference voltage provided from development board
2, 4, 6, 8, 10,
GND or return path
12, 14
All information provided in this document is subject to legal disclaimers.
Rev. 1.0 — 15 April 2024
UM90029
Nexperia B.V. 2024. All rights reserved
©
11 / 64
