Reference Qty Value
R31, R32, R43 3 TBD
R38, R39, R40 3 1k-1%
R49, R50 2 220
RV1 1 10k
SW1 1 EN
SW2 1 RMT
SW3 1 DIR
TP1, TP2 2 GND
TP3 1 PGOOD
U1 1 MCP1754S
U2 1 LT8630
U3, U4, U5 3 MIC4104YM
U6, U7, U8 3 MCP6566R
U9 1 CBT3251
UM90029
Submit document feedback
User manual
Footprint
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Resistor_SMD:R_0805_2012Metric_Pad1.20x1.40mm_HandSolder
Resistor_SMD:R_0603_1608Metric_Pad0.98x0.95mm_HandSolder
Potentiometer_THT:Potentiometer_Bourns_PTV09A-1_Single_Vertical
Switches:EG1218
Switches:EG1218
Switches:EG1218
TestPoint:TestPoint_THTPad_D3.0mm_Drill1.5mm
TestPoint:TestPoint_THTPad_D1.5mm_Drill0.7mm
Package_TO_SOT_SMD:SOT-23
ICs:TSSOP-20-16-1EP_4.4x6.5mm_P0.65mm_EP2.15x3.35mm
Package_SO:SOIC-8_3.9x4.9mm_P1.27mm
Package_TO_SOT_SMD:SOT-23-5
Package_SO:TSSOP-16_4.4x5mm_P0.65mm
All information provided in this document is subject to legal disclaimers.
Rev. 1.0 — 15 April 2024
NEVB-MCTRL-100-01-3INV-001-01 motor driver evaluation kit
Manufacturer Mfg Part No
YAGEO RC0805FR-101KL
YAGEO RC0603JR-07220RL
BOURNS PTV09A-4225U-B103
E-SWITCH EG1218
E-SWITCH EG1218
E-SWITCH EG1218
KEYSTONE 5288
MICROCHIP MCP1754ST-5002E/CB
TECHNOLOGY
ANALOG DEVICES LT8630EFE#PBF
MICROCHIP MIC4104YM
TECHNOLOGY
MICROCHIP MCP6566RT-E/OT
TECHNOLOGY
NEXPERIA CBT3251PW,118
UM90029
DNP
DNP
DNP
DNP = DO NOT POPULATE
