1. Introduction

The BLDC motor driver kit provides a full motor drive solution for 12 V - 48 V, 1,000 W, 3-phase
BLDC motors. The kit contains PCBs designed for the Nexperia
using the kit users must read the important
terms and conditions
Included in BLDC motor driver kit:
•
•
•
•
•
•
•
•
•
Not included in BLDC motor driver kit:
•
The modular design of the BLDC motor driver kit allows for different motor controllers, gate drivers,
MOSFETs and motors to be used. In addition, each board provides convenient test points for
power, motor drive, and sensing signals to aid with development and testing with Nexperia's
LFPAK56 MOSFET family.
The motor controller board is designed for the Leonardo R3 and Nucleo development board form
factors. The supplementary firmware is compatible with the Leonardo R3 development board
or ATMEGA32u4 micro controller to aid in the evaluating of 3-phase BLDC applications. The
Leonardo R3 development board, motor controller board, and 3-phase inverter board are shown in
Fig.
Fig. 1. Leonardo R3 development board, motor controller board and 3-phase inverter board
A simplified block diagram of the motor control kit is shown in
UM90029
Submit document feedback
User manual
NEVB-MCTRL-100-01-3INV-001-01 motor driver evaluation kit
of use.
Motor controller board (NEVB-MCTRL-100-01)
3-phase inverter board (NEVB-3INV-001-01)
Leonardo R3 development board
USB-A to Micro USB cable
Flat head screwdriver
Pluggable terminal block connectors
M5 pozidriv screws
3-phase BLDC motor with Hall-effect sensors (42BLS40-24-01)
Motor control firmware (for trapezoidal control of BLDC motors using Hall-effect sensors). Note:
other types of control and motors are supported
Bench top power supply with complimentary cables
1.
All information provided in this document is subject to legal disclaimers.
Rev. 1.0 — 15 April 2024
LFPAK56 MOSFET
safety precautions. By using this kit you agree to the
Fig. 2.
UM90029
family. Before
Nexperia B.V. 2024. All rights reserved
©
3 / 64
