- Page 1 Instruction Guide 40477G Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@Holman.com 20231207R1 DATE: ________________...
-
Page 2: Table Of Contents
Trim Removal Tool * Sold Separately. Before You Begin • Read all instructions prior to assembling or installing any Holman product. • Always locate your installation locations prior to performing any work. • ENSURE SAFETY WHILE INSTALLING OR DRILLING INTO VEHICLE. -
Page 3: Parts List
Instructions – 40477G Parts List Hardware Step 1 – Remove Factory Rear Threshold • Remove rear threshold using trim removal tool. • Discard factory rear threshold. Rear Threshold Step 2 – Mark Holes For Rear Threshold • Place rear threshold into rear of van. -
Page 4: Step 3 - Install Plus Nuts
Instructions – 40477G Step 3 – Install Plus Nuts DO NOT drill beyond depth of floor or upper installation surface. Always check for wires, fuel tanks and lines, brake lines and other important vehicle functionality items prior to drilling and installing all products. -
Page 5: Step 5 - Mark Holes For Door Threshold
Instructions – 40477G Step 5 – Mark Holes For Door Threshold • Place slider threshold into doorway of van. Be sure to have the flanges in the down position. • While applying firm pressure against threshold, mark the four holes onto the floor or floor mat.
