Summary of Contents for Holman 40476GR
- Page 1 Instruction Guide 40476GR Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@holman.com 20240115R1 DATE: ________________...
-
Page 2: Table Of Contents
• Any previously installed flooring must be removed prior to installing Holman flooring. • Floor must be assembled in vehicle. • 40475HW hardware kit may be necessary to install some accessories to Holman flooring. (40475HW sold separately). • 40477G threshold kit must be installed when installing Holman flooring. (40477G sold separately). -
Page 3: Parts List
Instructions – 40476GR Parts List Hardware For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 2... -
Page 4: Step 1 - Remove Factory D-Rings
Note: Discard any OEM spacer or retaining washers included with the OEM D-Ring. • Using M10 x 50mm hex head bolt, M10 lock washer, OEM D-Ring (if desired) and 3/8” fender washer, bolt through Holman floor at OEM D-Ring locations. M10 Lock Washer GO BACK AND TIGHTEN ALL HARDWARE. -
Page 5: Attaching Accessories To Floor
Note: Spacers are typically included with Holman accessories. • Determine installation location. • Drill a 1-1/8” hole through Holman floor in each mount location. Be sure not to drill through metal van floor with 1-1/8” drill bit. • In the center of each hole, install a plus nut using the instructions below.
