Installation Guide
40463
Holman
Rancho Cordova, CA 95742
800-343-7486
InstallationSupport@Holman.com
20221102R1
DATE: ________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40463 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Holman 40463

  • Page 1 Installation Guide 40463 Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@Holman.com 20221102R1 DATE: ________________...
  • Page 2: Table Of Contents

    Instructions – 40463 PLEASE READ ALL INSTRUCTIONS AND WARNINGS PRIOR TO ASSEMBLING, INSTALLING, AND USING THIS PRODUCT. Warning Always check for wires, fuel tanks and lines, brake lines and other important vehicle functionality items prior to drilling and installing all products.
  • Page 3: Parts List

    Instructions – 40463 Parts Hardware For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 2...
  • Page 4: Step 1 - Mark Holes For Door Threshold

    Instructions – 40463 Step 1 – Mark Holes For Door Threshold  Place Slider Threshold into slider doorway of van. Be sure to have the flanges in the down position.  While applying firm pressure again threshold, mark the four holes onto the floor or the floor mat.
  • Page 5: Step 3 - Install Door Threshold

    Instructions – 40463  Using the 9/16” box wrench, hold the plus nut tool stationary and then tighten hex head bolt until plus nut is tightly gripping and does not spin when hex bolt is loosened.  DO NOT overtighten plus nut.
  • Page 6: Step 4 - Mark Holes For Rear Threshold

    Instructions – 40463 Step 4 – Mark Holes For Rear Threshold  Place rear threshold into rear of van.  Be sure to have the flanges in the down position.  While applying firm pressure again threshold, mark the four holes onto the floor or the floor mat.
