Fault finding is performed via
Vehicle Diagnostic Tester .
Notes on MOST Bus
The optical Data Bus "MOST Bus" is used in addition to the CAN
Bus.
A fiber-optic cable is used as a "connecting cable". Fiber optic
cables are routed inside corrugated tubes for protection.
Replace complete fiber optic cable if possible.
The front surface of the connectors must not be dirty.
If disconnecting the connectors: Attach Fiber-Optic Repair Set -
Connector Protective Caps - VAS6223/9- .
When installing fiber optic cables, make sure not to go below the
minimum bending radius of 25 mm. Do not crush or kink fiber optic
cables.
Fiber-optic cable, repairing. Refer to
⇒ "1.1 General Repair Information", page 1
1.2 Component Location Overview - Info‐
tainment System
⇒ "1.2.1 Component Location Overview - Infotainment System,
Sedan", page 9
⇒ "1.2.2 Component Location Overview - Infotainment System,
Wagon", page 11
1.2.1 Component Location Overview - Infotainment System, Sedan
Guided Fault Finding
.
Golf 2015 ➤ , Golf Variant 2015 ➤
Communication - Edition 02.2015
on the
9
1. Infotainment System
