5

Telephone System

⇒ "5.1 Cell Phone Preparation", page 39
⇒ "5.2 Component Location Overview - Telephone System", page
40
⇒ "5.3 Mobile Communication 2-Way Signal Amplifier J984 , Re‐
moving and Installing", page 42
⇒ "5.4 Telephone Microphone R38 , Removing and Installing",
page 43
⇒ "5.5 Storage Compartment with Cell Phone Interface R265 ,
Removing and Installing", page 44
5.1

Cell Phone Preparation

⇒ "5.1.1 Cell Phone Preparation, Bluetooth Hand-Free Calling,
9ZX", page 39
5.1.1 Cell Phone Preparation, Bluetooth
Hand-Free Calling, 9ZX
®
The Bluetooth hands-free calling function is integrated in the In‐
formation Electronics Control Module 1 - J794- .
®
Bluetooth is connected via the Cellular Telephone - R54- .
The Bluetooth Antenna - R152- is integrated in the Information
Electronics Control Module 1 - J794- .
The hands-free calling consists of the following components:
♦ Front Information Display Control Head - J685-
♦ Information Electronics Control Module 1 - J794- with Blue‐
tooth Antenna - R152-
♦ Storage Compartment with Cell Phone Interface - R265-
♦ Telephone Microphone - R38-
The Information Electronics Control Module 1 - J794- is part of
the hands-free setup.
Fault finding is performed via
Vehicle Diagnostic Tester .
Antenna wires, repairing. Refer to ⇒ Electrical Equipment; Rep.
Gr. 97 ; Antenna Wires, Repairing .
®
Notes on Bluetooth Technology
A standardized radio connection is used to transfer data between
the Information Electronics Control Module 1 - J794- and Cellular
Telephone - R54- - Bluetooth
An additional transmitter/receiver unit is installed in the Informa‐
tion Electronics Control Module 1 - J794- . A Bluetooth Antenna
- R152- connects the Information Electronics Control Module 1 -
J794- and the Cellular Telephone - R54- so that the Cellular
Telephone - R54- can be operated without a wire connection.
The range is approximately 10 meters.
Guided Fault Finding
®
Technology.
Golf 2015 ➤ , Golf Variant 2015 ➤
Communication - Edition 02.2015
using the
39
5. Telephone System
