5.2 Component Location Overview - Tele‐
phone System
⇒ "5.2.1 Component Location Overview - Telephone System, Se‐
dan", page 40
⇒ "5.2.2 Component Location Overview - Telephone System,
Wagon", page 41
5.2.1 Component Location Overview - Telephone System, Sedan
1 - Telephone Microphone -
R38-
❑ In the Front Interior
Lamp - W1-
❑ Removing and instal‐
ling. Refer to
⇒ "5.4 Telephone Mi‐
crophone R38 , Remov‐
ing and Installing", page
43 .
2 - Information Electronics
Control Module 1 - J794-
❑ In the glove compart‐
ment
❑ Connector assignment.
Refer to ⇒ Wiring dia‐
grams, Troubleshooting
& Component locations.
❑ Removing and instal‐
ling. Refer to
⇒ "1.4 Information Elec‐
tronics Control Module 1
J794 , Removing and In‐
stalling", page 13
3 - Bolt
❑ 2 Nm
❑ Quantity: 2
4 - Storage Compartment with
Cell Phone Interface - R265-
❑ Removing and instal‐
ling. Refer to
⇒ "5.5 Storage Com‐
partment with Cell
Phone Interface R265 ,
Removing and Instal‐
ling", page 44 .
5 - Cover
No illustration:
♦ Mobile Communication 2-Way Signal Amplifier - J984- . Refer
to
⇒ "5.3.1 Mobile Communication 2-Way Signal Amplifier J984 ,
Removing and Installing, Sedan", page 42
