10. Release Film (FEP) Replacement
1
Recycle the resin in the resin vat back into the
original bottle , then clean up. (Note: Please make
sure there are no residue matter left inside the Vat)
3
Gently remove the protective film on
the front and back of the release film.
5
Press into the bottom of the vat, and tighten the
screws diagonally across from each other one at
a time. (Note: Make sure there are no debris
between the fixing plate and release film)
Tips:
① The diagram is a reference for the film change procedure, please refer to the physical product; if there are excess edges after installation
of the release film, you will need to cut them off.
② It is recommended to replace the release film when it has been used for more than 200 hours.
2
Remove all the screws at the bottom of the resin vat, take
out the fixing plate and the release film. (Note: The fixing
plate andthe vat bottom need to be cleaned)
4
Align the release film positioning holes
with the fixing plate positioning posts.
6
Make sure the release film is flat and tight after installation.
(Note: If not flat or loose, please check whether the screws
are locked or the release film is abnormal)
01 12
Thickness： 0.3mm
×
Light Transmittance
Parameters
Size： 286*198mm
92%
