O P E R A T I N G I N S T R U C T I O N S
GM700 Ex
Gas Analyzer,
Cross-Duct Version

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM700 Ex and is the answer not in the manual?

Questions and answers

Related Manuals for SICK GM700 Ex

Summary of Contents for SICK GM700 Ex

  • Page 1 O P E R A T I N G I N S T R U C T I O N S GM700 Ex Gas Analyzer, Cross-Duct Version...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    Tools required.................... Material required..................Preparing the sampling point..............8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 4 7.12 Fitting the weather hood (option)............7.13 Starting measuring operation..............7.13.1 Operating states..............O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 5 Communication fault between evaluation unit and receiver 10.5 Ex operation malfunction................. 10.6 Error messages..................8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 6 13.4 Possible ambient temperatures............... 106 13.4.1 Ambient temperature ranges..........106 O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 7: About This Document

    8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 8: Symbols And Document Conventions

    Hazard which could result in property damage. Note Hints O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 9: Information Symbols

    Important technical information for this product Important information on electric or electronic functions 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 10: Safety Information

    – IEC 60079-19: Equipment repair, overhaul and reclamation O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 11 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 12 The person setting the system up is responsible for the safety of the system in which the device is integrated. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 13: Warning Information On The Device

    May 8, 2019 Figure 2: Laser warning sign on device 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 14: Intended Use

    Please contact SICK Customer Service. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...
  • Page 15 Must be passed on to new owners. ► 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 16: Product Description

    Min. gas temperature Max. gas temperature QR code Month/year O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 17: Device Variants

    Cover plate for purge air fixture of the sender/receiver unit • Weatherproof cover • Purge air unit 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 18: Layout And Function

    The protective gas can be air suctioned in from the non-potentially explosive atmosphere or an inert gas. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 19: Function Of The Pressurized Enclosure

    “Function control” (relay 3) is signaled per digital output during output of the zero and check point. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 20: Explosion Protection In Accordance With Atex

    After switching off the main power supply: Wait 20 minutes before ► opening the enclosure. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 21: Zone Of Use Of Gm700 Ex 3G Components

    Controlling the overpressure in the enclosure 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 22: Sender/Receiver Unit - Evaluation Unit Connecting Hose

    GMM700 and GMA700 are secured additionally with sprocket discs. These sprocket discs may not be removed. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 23: Transport And Storage

    Store all components of the measuring device in a dry, clean area. ► 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 24: Mounting

    • Local work safety regulations must be observed O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 25: Tools Required

    Preparing the sampling point • Feed and drain for protective gas 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 26: Gm700 Ex Scope Of Delivery

    Carry out assembly according to the project planning and the Inspection protocol. The dimensions specified in the drawings are guidelines and can deviate from project planning. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 27: Overview Of Installation Steps (Duct-Side Preparation)

    Fit purge air unit or units. see "Installing the purge air unit", page 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 28: Installing The Flange With Tube

    Determine flange - flange distance and measuring distance. ► O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 29 The installation steps for the flanges with tube are identical for the sender/receiver unit and reflector unit. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 30 Other devices or fittings must not cut or interrupt the measuring device beam path. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...
  • Page 31 Align the flange with tube on the reflector side so that the light spot appears centred in the target. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 32: Install The Evaluation Unit

    Ensure the protective gas inlet and outlet are in a horizontal axis. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...
  • Page 33 The pressure losses are noticeable when the purge medium flow rate is too low so that the device is possibly not completely pre-purged. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 34: Installing The Purge Air Unit

    For information on installing the purge air unit, see the Operating Instructions of the purge air unit. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 35: Electrical Installation

    First switch the power supply on when the sender/receiver unit and the control ► unit are closed. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 36 Ensure the potential equalization is connected during all work on the device ► described in these Operating Instructions. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 37 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 38: Connection Overview

    M16 x 1.5 5 - 10 mm 6 Nm O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 39: Connecting Interfaces

    The analog input assignment shown in the following Chapter is the default setting and may not be modified. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 40 Max. outer capacity Max. outer inductivity L/R ratio (inductivity/resistance) O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 41 3 = digital output (NO contact) for function check 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 42: Connecting The Connecting Hose To The Sr-Unit On The Evu

    – Mark the disconnecting device as disconnecting device for the GM700 Ex. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 43: Connecting The Fs840 Ex Overpressure Control

    Check the gland screw fittings, sealing plugs and flanges for leak tightness and ► tight seat. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 44 98 and FS840 Operating Instructions. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 45: Electrical Connection Of Sr-Unit

    A potential equalization not connected properly or missing can lead to malfunctions in device operation. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 46: Connecting The Potential Equalization On The Sr-Unit

    ) of the plant ground tight to the screw terminal. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 47 Potential equalization connection on Ex control unit Potential equalization connection on evaluation unit 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 48: Commissioning

    Prerequisites for successful commissioning Required Operating Instructions: O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 49: Material Required

    "Fitting the purge air fixtures on the with tube. flange with tube", page 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 50: Assembly Drawing

    Purge air fixture Reflector Flange with tube Differential pressure sensor O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 51: Zero Adjust On The Measuring Path Free From Sample Gas

    Device flange, sender/receiver unit Device flange, reflector unit 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 52: Aligning Device Flanges And Purge Air Fixtures

    Remove the protective cap from the adjustment tube. Insert the adjustment device with tube into the device flange. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 53: Fitting The Purge Air Fixtures On The Flange With Tube

    Install the purge air fixture according to the Figure. ► 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 54: Fitting The Device Flange On The Purge Air Fixture

    Fitting is easier when the sender/receiver is taken off the device flange beforehand, see "Removing the SR-unit resp. reflector unit", page O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...
  • Page 55 Push the two hose clamps over the sealing ring and screw tight. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 56: Feeding Protective Gas

    Only use protective gas corresponding to the specifications, see "Technical data for Protective gas", page O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 57: Switch The Pressurized Enclosure On

    Quick-release fasteners of the sender/receiver unit Intermediate enclosure Hinge pin 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 58: Optical Fine Alignment Of The Sender/Receiver Unit

    After successful alignment, push the lever of the alignment tool back to its original position and secure it with a quarter turn. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 59: Fitting The Weather Hood (Option)

    Pull the installation plate upwards and remove it from the hood. Remove the bottom mounting ring. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 60 Figure 36: Fitting weather hood. Hood Installation plate O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 61: Starting Measuring Operation

    Adjusting amplification to changed transmission Measuring operation MEASURING 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 62: Select The Ambient Temperature Range

    "Possible ambient temperatures", page 106. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 63: Operation

    Ensure an Ex-free atmosphere exists when opening the GMA700. ► 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 64: Function Buttons

    Function Back Returns to next higher level menu. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 65: Menu Tree Of The Evaluation Unit

    Cross-Duct: OH Cross-Duct: Reflector 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 66: Menu Tree Parameter

    Range high: 0 ... 999999 Cycle Out: No, Yes O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 67 GMM700/DSP ■ XXXXXXX XXXX ■ Service Not defined 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 68: Menu Tree Calibration

    Output of the complete parameter set via the RS-232 Service interface O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 69: Operating Using The Serial Interface

    Start measuring operation/switch to measuring operation Syntax: GM700<<GOTO MEAS 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 70: Serial Interface Commands - Diag

    Use a 2 mm precision screwdriver to adjust the display contrast setting. ► O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...
  • Page 71 OPERATION Figure 38: Rotary potentiometer for display contrast 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 72: Maintenance

    Wait 20 minutes after switching off the main power supply before opening the ► enclosure. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 73 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 74: Maintenance Plan

    "Maintenance work on the FS840", sures page 76 O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 75: Expendable, Wearing And Spare Parts

    Never change parameters without authorization. ► 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 76: Maintenance Work On The Fs840

    Never open the device when the room is too small. ► O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 77: Visual Check Of The Sender/Receiver Unit And Evaluation Unit

    Check flanges and screw fittings for tight seat. ► 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 78: Cleaning The Optical Interfaces

    Flap the target upwards and check the SR-unit window underneath for contamina‐ tion. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 79: Etalon Tool

    Observe the relevant Operating Instructions when using the filter box. ► 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 80 Fasten the reflector enclosure to the filter box with 4 screws. ► O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 81 Leave operating mode “Box measuring” on the EvU with the return button. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 82: Checking The Gas Analyzer With Test Cell Gmk10

    ► Carrying out the check is described in the GMK10 Operating Instructions. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 83: Checking The Evaluation Unit

    Cleaning the purge air unit: 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 84 Put the purge air unit back into operation. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 85: Troubleshooting

    Clean work is required. Do not leave any metal cuttings in the device. ► 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 86: Monitoring And Diagnostic System

    Warning and error messages are stored in the built-in message memory of the evalua‐ tion unit. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 87: Device Not Functioning

    3 Exchange the evaluation unit. 4 Contact SICK Service. 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 88: Communication Fault Between Evaluation Unit And Receiver

    Restart device; see above. ► If not successful, contact Service. ► O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 89 Reference channel signal too low. Contact Service. ► Zero gas measurement for 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 90: Warning Messages

    Wait 20 minutes after switching off the main power supply before opening the ► enclosure. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 91: Corrosion On Flange

    Unsuitable materials Check project planning. Corrosion on flange. ► 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 92: Decommissioning

    Take appropriate safety measures: Only then swivel the sender/receiver unit or ► reflector unit out. O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 93: Decommissioning Ex-Relevant Subassemblies

    Protection when working on the stack or hot or aggressive sample gases 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 94: Preparing The Device Ready For Shipping

    Cleaning the optical interfaces, see "Cleaning the optical interfaces", page O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 95: Environmentally Compatible Disposal

    Electronics: Capacitors, rechargeable batteries, batteries • Display: Liquid of LC-Display 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 96: Technical Data

    Test gas: Swagelok 1/4″ stances • Purge gas: Swagelok 1/4″ O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 97: Reflector Unit Gm700

    Type: Button cell 3V CR2032 • Chemical system: Lithium-Ion (Li-Ion) 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 98: Technical Data For Pressurized Enclosure System

    Approx. 6 minutes 12.6.5 Pressurized enclosure system settings O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 99 2 mbar (0.03 psi) (relative) Signal pressure 1.5 mbar (0.022 psi) (relative) 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 100: Dimension Drawings: Sender/Receiver Unit

    (9.00) Figure 44: GM700 Ex 3G sender/receiver unit (all dimensions in mm) O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 101: Dimension Drawing, Reflector Unit

    Dimension drawing, reflector unit Figure 45: Reflector unit (dimensions in mm) 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 102: Dimension Drawings, Purge Air Fixtures, Without Electronics

    (1.57) Figure 46: GM700-Ex purge air fixtures, without electronics (all dimensions in mm) O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK...

  • Page 103: Dimension Drawing, Purge Air Unit

    Figure 47: Dimensions, purge air unit (all dimensions in mm (inch)) 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 104: Dimension Drawings, Evaluation Unit With Pressurized Enclosure System Fs840

    Ø 200 Figure 49: Flange with tube, DN125 (dimensions in mm) O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...

  • Page 105: Dimension Drawing, Weather Hoods

    Figure 51: Weather hood for reflector unit (dimensions in mm) 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...

  • Page 106: Annex

    –10 ... 40 263 ... 313 14 ... 104 O P E R A T I N G I N S T R U C T I O N S | GM700 Ex 8019541/1K5X/V1-2/2024-02 | SICK Subject to change without notice...
  • Page 107 X Attention: These ranges may not be used for Ex applications! 8019541/1K5X/V1-2/2024-02 | SICK O P E R A T I N G I N S T R U C T I O N S | GM700 Ex Subject to change without notice...
  • Page 108 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail office@sick.com.gr E-Mail sales.gsg@sick.com Hong Kong Slovakia Phone +852 2153 6300 Phone +421 482 901 201 E-Mail ghk@sick.com.hk E-Mail mail@sick-sk.sk Detailed addresses and further locations at www.sick.com SICK AG | Waldkirch | Germany | www.sick.com...

Table of Contents
