4. Specifications

Operating Temperature Range
Operating Humidity Range
Input Video Signal
Input DDC Signal
Data Transfer Speed Rate
Input Port
Output Ports
Video Formats Supported
Vertical Frequency Range
Supported Audio Formats
Transmission Distance
Power Consumption
Dimensions (L x W x H)
Net Weight

5. Product Requirements

Front Panel:
Type
1 Power Indicator
2 HDMI In Indicator
3 HDMI Out Indicator
4 Reset
-5°C ~ 40°C (+23°F ~ 140°F)
5 to 90% RH (No Condensation)
0.5 - 1.0 volts P-P (TTL)
5 volts p-p (TTL)
18Gbps (Maximum)
1 x HDMI
4 x CAT5e/6 , 1 x HDMI Loop-out
DTV/HDTV: 480P / 576P / 720P / 1080P / 4K
VESA Resolution: 1280*720 / 1920*1080 / 3840*2160
60Hz
LPCM 2.0 / 5.1, DTS 5.1 Dolby Digital, Dolby Digital+,
Dolby True HD
60m (197ft.) at 4K@60Hz
12.5W (Max)
TX: L229.5 x W113.4 x H24mm
RX: L110.2 x W68.3 x H18mm
TX: 1300g, RX: 1600g (4 pcs)
Red power indicator shows working data
Blue light indicates working connection
Blue light indicates working connection
Reset via long press for 3 secons
6
