5
EDID
6
FW
Rear Panel:
Type
1
HDMI In
2
HDMI Loop
3
CAT5e/6
4
IR IN
5
IR Out
6
Audio Out
7
DC 12V
Receiver:
Type
1
DC 12V
2
IR In
3
IR Out
4
CAT5e/6
1080P60 2.0CH ~ 4K@60 2.0/5.1CH
1 x USB cable for upgrade
HDMI A port. Supports up to 4K@60Hz
1 x HDMI Loop output
4 x UTP ports to transmit signal to the receivers
1 x 3.5mm Port. Connect with IR TX cable
1 x 3.5mm Port. Connect with IR TX cable
1 x Analog, 1 x Toslink output
1 x power port
1 x power port
1 x 3.5mm Port. Connect with IR RX cable
1 x 3.5mm Port. Connect with IR RX cable
1 x RJ45 port to connect to the transmitter
7
Function
Function
