User Manual
DVI Pure Fiber Optic Extender Dual Link
ODC
Dtrovision LLC
9A Bergen Turnpike
Little Ferry, NJ 07643 USA
Tel:
1-201-488-3232
Fax: 1-201-621-6118
www.purelinkAV.com
For order support, please contact your Distributor or Reseller.
For technical support, check with the Email:
support@dtrovision.com
Cautions:
1. Purelink logo is our own trademark of Dtrovision LLC.,Inc.
2. Any of the products may be changed without any notice in order to improve the function
of the product.
3. The design and specification of the product may be changed without any prior notice.
Advertisement
Table of Contents
Related Manuals for PureLink DVI Pure Fiber Optic Extender Dual LinkODC
Summary of Contents for PureLink DVI Pure Fiber Optic Extender Dual LinkODC
-
Page 1: User Manual
For technical support, check with the Email: support@dtrovision.com Cautions: 1. Purelink logo is our own trademark of Dtrovision LLC.,Inc. 2. Any of the products may be changed without any notice in order to improve the function of the product. 3. The design and specification of the product may be changed without any prior notice. - Page 2 Package Content Each DVI Pure Fiber Optic Extender Dual Link package includes the following items; ODC TX/RX Unit DVI-D Dual Link Cable – 1.2m, 2pcs 12V Power Adapter: 2 pcs User manual...
-
Page 3: Table Of Contents
Contents Contents Description, General Specification Environmental and Reliability Specifications Main Features Video Connection Mechanical Specification Technical Specification Warranty Information Troubleshooting 1-1 Contents... -
Page 4: Description, General Specification
Description, General Specification Send DVI video signal and digital audio signal to long distance using pure fiber optic cable (multimode 8 strands) Owing to its compact size and low power design ODC connects monitors only for DVI-D dual link, PDP, and projectors at the lowest price ... -
Page 5: Environmental And Reliability Specifications
Environmental and Reliability Specifications Recommended environmental conditions for the operation are temperature range of 10°C~40°C, non-condensing humidity levels of 10%-80%, and altitude ceiling of 3,000 meters (9,840 feet). Environmental limits for transportation are temperature range of -25°C ~ 60°C, non- condensing humidity levels of 5%~95%, and altitude ceiling of 15,000 meters (49,200feet) Environmental limits for storage are established at temperature range of -20°C~45°C, non- condensing humidity levels of 5%~95%, and altitude ceiling of 3,000 meters (9,840 feet) -
Page 6: Main Features
Main Features High Quality Picture - No Signal Loss and Digital Noise Free Our ODC is built to deliver the highest quality picture preserving the native resolutions of the video sources without any signal loss. At the same time, the digital noises that may affect the picture quality will be eliminated. -
Page 7: Video Connection
Video Connection Step 1: Ensure the digital video/audio source and display is turned off Step 2: Connect the digital DVI-D Dual Link cable and fiber optic cable to ODC module Step 3: Connect power adapter to the transmitter (TX/RX) module of ODC Step 4: Connect power code to the power adapter and plug in to power outlet Step 5: Turn on the display Step 6: Turn on the source... -
Page 8: Mechanical Specification
Mechanical Specification x111x35 mm / 4.9 „‟ x 4.4‟‟ x 1.4‟‟ (inch) Dimension: 125 TX Functioning part DVI In: DVI-D Dual Link Input port SPDIF In: Digital Audio (Optical, Coaxial) Input port DIP S/W: Digital Audio (Optical, Coaxial) selection switch A-R2-G2-B2-R1-G1-B1-C: Fiber optic cable connection port DC-12V: power input port Display part... -
Page 9: Technical Specification
Technical Specification Data transmission speed: 3.3 Gbps (Per color) Digital Video Bandwidth: 25~268.5 Mhz Resolution: Up to QXGA (2560x1600)@60Hz / 1080P Input/output signal standard: Digital RGB, TMDS, SPDIF Maximum length: 2560*1600p -> 500m (1640ft) Optional -> 1000m (3280ft) Light Source: 850 nm Vcsel Fiber Optic cable: 50/125 &... -
Page 10: 1-8 Warranty Information
Warranty Information 2(Two) Year Warranty Dtrovision LLC warrants this DVI Pure Fiber Optic Extender Dual Link to be free from defects in workmanship and materials, under normal use and service, for a period of two (2) years from the date of purchase from Dtrovision LLC or its authorized resellers. If a product does not work as warranted during the applicable warranty period, Dtrovision LLC shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase... -
Page 11: Troubleshooting
Troubleshooting The DVI Pure Fiber Optic Extender Dual Link is designed for years of trouble free service, please refer to the troubleshooting chart below if experiencing issues with the device. Problem Solution No picture(or signal) 1. Ensure the power LED is illuminated. 2.
