Relevant Models

This document is only applicable to the models listed below.
Model Name
ioThinx 4533-LX
ioThinx 4533-LX-T

Package Contents

The following items are included in the product package.
The ioThinx 4530 Series device
Quick installation guide (Printed)
Warranty card

Hardware and Software Requirements

You will need the following hardware and software to use the ioThinx 4530 Series.
A power source that provides 12 to 48 VDC, and power wires
A PC running Linux OS (we recommend Debian 11, kernel 5.10) and an Ethernet cable
45MR/ML modules, if available

Safety Precautions

Please observe the following safety precautions when installing and using the ioThinx 4530 Series:
DANGER
Never work on the device while the power source is switched on. Disconnect all power sources to the
device before performing installation, repair, or maintenance work.
DANGER
Disconnect the power when you want to remove or replace components, or disconnect equipment unless
the area is known to be free of ignitable substances.
If you connect or disconnect the Removable Terminal Block when field power is applied, an electrical
arc can occur. This could cause an explosion when installed in hazardous locations. Ensure that power
is removed, or the area is non-hazardous before installation.
If you connect or disconnect wiring while the power is on, an electrical arc can occur. This could cause
an explosion in hazardous environments. Ensure that power is removed, or the area is nonhazardous
before installation.
Do not disconnect the unit unless the power has been disconnected or the area is known to be
nonhazardous. In a hazardous area, the unit must be powered down before removing it.
ioThinx 4530 Series Hardware User Manual
Description
Controller with Cortex-A7 1 GHz dual-core CPU, 512 MB RAM, 3-in-1 serial ports,
Linux OS, -20 to 60°C operating temperature
Controller with Cortex-A7 1 GHz dual-core CPU, 512 MB RAM, 3-in-1 serial ports,
Linux OS, -40 to 75°C operating temperature
6
