Introduction

1 Introduction

1.1 Symbols and illustrations

Warning notices
In these instructions, warning notices are used to warn against material damage and injuries.
Always read and observe these warning notices.

Observe all the measures that are marked with the warning symbol and signal word.

Warning symbol Warning
DANGER
WARNING
CAUTION
Further symbols and means of representation
Important information and technical notes are highlighted to explain correct operation.
Symbol Meaning
means "important note"
Information to prevent property damage, to understand or optimise the operation se-
quences.
means "additional information"
 Symbol for an action: This means you have to do something.
□
If there are several actions to be taken, keep to the given order.
1

1.2 Reference documents

Type
Wiring diagram
Additional wiring diagram
User manual
Safety analysis
Production drawings
The diagrams are subject to change without notice. Use only the most recent version.
4
Meaning
Danger to persons.
Non-compliance will result in death or serious injuries.
Danger to persons.
Non-compliance can result in death or serious injuries.
Danger to persons.
Non-compliance can result in minor injuries.
Name
160924 Automatic sliding doors DCU1-NT
164883 DCU1-NT-OP
193098 Installation and service instructions
187393 Safety analysis sliding doors EN16005 DE
200772 Inst.-DWG; SET; MCR
GEZE MCRdrive
