Installation

4 Installation

4.1 Tools and aids required

Tool
Tape measure
Marking pen
Torque spanner
Allen key
Open-ended spanner
Screwdriver set
Side-cutting pliers
Crimping pliers for cables
Wire stripper
Multimeter
Display programme switch/Service terminal
ST220/GEZEconnect

4.2 Preparations to be made on-site

Installation material is not included in the scope of delivery and must be chosen suitable

for the substrate and the static load.
 Check the preparations made on-site by the customer to ensure proper installation:
 Check the type and load capacity of the façade construction or suspending frame
 Check that the installation surface is level
Check that the finished floor is level

 Check the requirements of the wiring schematic
 Check the on-site door frame against the GEZE specification drawing

4.3 Installing the drive unit

Protect the running surface against damage and soiling. Remove any soiling after installa-

tion.
 Mark the fastening drill holes for the drive unit (see dimension specifications on the drawing).
