Operating Guide | Voltage Measurement Option OC7V0

Only 1 Voltage Measurement Option OC7V0 can be connected to 1 option extender.

Figure 7: Terminal Locations on the Voltage Measurement Option OC7V0

Table 3: Connector Types for Voltage Measurement Option OC7V0

Terminal

X52, X53 (TE CONNECTIVITY type 282843-3)

X64 (TE CONNECTIVITY type 282841-2 or PHOENIX CONTACT type1888687)

X84 (Firecomms Ltd type FB2M5LVR(-P))

NOTICE

Description

Screw connectors on PCB, not pluggable

Plug-in type for the fiber optic cable

AQ476649821259en-000101 / 136R0332 |
