D070-A
● Several options are available for powering the sensor.
Options
● Power and sensor supply (Types PB, PD, PL, PM, PX, in various combinations)
● Display backlight (Type ZB).
3.3
INSTALLATION EXAMPLE
Following parts can be recognized in below installation example.
1. Front cover
2. Display
FW_D070-A_M_v0501-01_EN
1
2
5
6
Fig. 3:
Installation example D070-A
3. Label
4. Protective earth
connection
3
4
7
5. Keys
6. Mounting panel
User Manual
8
7. Clamp
8. Back side cover
Page 7
