T1200 Long Handrail Kit (T1200-LH)
THE FOLLOWING TOOLS ARE RECOMMENDED FOR EASIER ASSEMBLY:
ALLEN WRENCHES SET
(6mm)
for the BODYCRAFT T1200 Treadmill
PHILLIPS SCREWDRIVER #2
w/ Magnetic TIP
Owner's Manual
1
For the Owner's Manual,
Assembly STEPS in
FULL COLOR
& additional
information,
scan this QR code.
Open your Camera
App and point it at
the QR Code
TORQUE WRENCH 3/8 DRIVE
w/ 6mm ALLEN
T1200-LH OM v1.2

Advertisement

loading
Need help?

Need help?

Do you have a question about the EXP Series and is the answer not in the manual?

Questions and answers

Related Manuals for BodyCraft EXP Series

Summary of Contents for BodyCraft EXP Series

  • Page 1 T1200 Long Handrail Kit (T1200-LH) for the BODYCRAFT T1200 Treadmill For the Owner’s Manual, Assembly STEPS in FULL COLOR & additional information, scan this QR code. Open your Camera App and point it at the QR Code THE FOLLOWING TOOLS ARE RECOMMENDED FOR EASIER ASSEMBLY:...
  • Page 2 Assembled Parts, Hardware & Tools List, TM1200-LH (Long Handrails) Part # Assembly Parts List T120-LH:001-ASM Frame, Handrail Extension, Left - Assembly T120-LH:002-ASM Frame, Handrail Extension, Right - Assembly T120-LH:003 Frame, Rear Support Tube, for both Upper & Lower Handlebars T120-LH:008 Bolt, Button Allen Head, M8 x 1.25p x 20mm L - BLK T120-LH:009 Bolt, Button Allen Head, M8 x 1.25p x 60mm L - BLK...
  • Page 3 Product Assembly, TM1200-LH (Long Handrail Kit) DECISION POINT If you are simultaneously assembling a If you are installing a T1200-LH (Long Handrail T1200 & Long Handrail Kit (T1200-LH), Kit) on a fully assembled T1200, Go to STEP 1 below o directly to STEP 3 (Page 5) TEP 1: Uninstall the Lt &...

  • Page 4: Product Assembly

    Product Assembly Product Assembly, TM1200-LH (Long Handrail Kit) TEP 2: Uninstall the “Short” Handrail Side Frames (Rt & Lt) and Hardware Recommended Tool: ALLEN WRENCH Part # Uninstall Parts Description T120:076 Handrail Side Frame, with Rubber Foam Grip, Left T120:077 Handrail Side Frame, with Rubber Foam Grip, Right T120:173 Bolt, Allen Head, M8 x 1.25P x 20mm L - BLK T120:174 Washer, Spring, M8 - BLK T120:175 Washer, Flat, M8 x Ø16 x T1.0 - BLK...
  • Page 5 Product Assembly, TM1200-LH (Long Handrail Kit) TEP 3: Assemble the Right Handrail Extension Frame - Assembly Please Hand Tighten All Bolts Until STEP 8 Part # Assembly Parts List T120-LH:002 Frame, Handrail Extension, Right -ASM - Assembly Bolt, Socket Allen Head, M8 x T120-LH:010 1.25p x 60mm L - BLK Bolt, Socket Allen Head, M8 x...
  • Page 6 Product Assembly, TM1200-LH (Long Handrail Kit) TEP 4: Assemble the Left Handrail Extension Frame - Assembly Please Hand Tighten All Bolts Until STEP 8 Part # Assembly Parts List T120-LH:001 Frame, Handrail Extension, Left -ASM - Assembly Bolt, Socket Allen Head, M8 x T120-LH:010 1.25p x 60mm L - BLK Bolt, Socket Allen Head, M8 x...
  • Page 7 Product Assembly, TM1200-LH (Long Handrail Kit) TEP 5a: GENTLY Tip Treadmill on it’s Side for EASY Access to the Bottom Frame Mounting Plates TEP 5b: Space Constraints and CANNOT Tip Treadmill on it’s Side?? Use a Solid Object min 12” tall on the Rear Frame Crossbar.
  • Page 8 Product Assembly, TM1200-LH (Long Handrail Kit) TEP 6a & 6b: Install on the Right Side, the Rear Support Tube Frame Part # Assembly Parts List Frame, Rear Support Tube, for both Upper T120-LH:003 & Lower Handlebars Bolt, Button Allen Head, M8 x 1.25p x 20mm T120-LH:008 L - BLK Bolt, Button Allen Head, M8 x 1.25p x 60mm...
  • Page 9 Product Assembly, TM1200-LH (Long Handrail Kit) TEP 7a & 7b: Install on the Left Side, the Rear Support Tube Frame Part # Assembly Parts List Frame, Rear Support Tube, for both Upper T120-LH:003 & Lower Handlebars Bolt, Button Allen Head, M8 x 1.25p x 20mm T120-LH:008 L - BLK Bolt, Button Allen Head, M8 x 1.25p x 60mm...
  • Page 10 Product Assembly, TM1200-LH (Long Handrail Kit) TEP 8: “Torque Time” on ALL Bolts from STEP 3 - 7 NOTE: These recommended torque Example of being specs should be followed for correct overtightened not using the assembly and safe operation of this recommended torque specs.
  • Page 11 Product Assembly, TM1200-LH (Long Handrail Kit) TEP 9a & 9b: Install on the Left & Right Handrail (Inner & Outer) Covers Recommended Tool: PHILLIPS SCREWDRIVER #2 w/ Magnetic TIP (The Longer Screws) Part # T1200 Parts Description T120:155 Handlebar Cover, Outer Left T120:156 Handlebar Cover, Outer Right T120:157...
  • Page 12 Product Assembly, TM1200-LH (Long Handrail Kit) DECISION POINT If you are simultaneously assembling a T1200 If you are finishing up the T1200-LH (Long & Long Handrail Kit (T1200-LH), Handrail Kit) on a fully assembled T1200, Go to STEP 10a below Go directly to the T1200 Owner’s Manual continue the assembly on...
  • Page 13 Detailed Parts List & Parts Exploded View, TM1200-LH (Long Handrail Kit) #155 & #157 #158 & #156 NOTE: Parts are not to scale Part # Detailed Parts List T120-LH:001 Frame, Handrail Extension, Left T120-LH:002 Frame, Handrail Extension, Right T120-LH:003 Frame, Rear Support Tube, for both Upper & Lower Handlebars T120-LH:004 Neoprene Foam, ID Ø38.1 x 3.0mm Thick x 1,000mm L, for Longer Upper Handrail - BLK T120-LH:005...
  • Page 14 Required Information BEFORE Initiating a Service Case The following information is needed to help expedite troubleshooting and to ensure the correct part(s) are sent if needed for a repair: What product / model # do you have? Unit serial number? Installed by a dealer or direct sale? Date of installation? Date of service issue?
