Indicator LEDs

The top of the FG2000e has an indicator LED. It changes colors and either blinks or glows solid to
communicate current states for the device.
LED Color
Blue
Green
White
Yellow
Red
The WAN/LAN connector ports also have indicator LEDs.
LED Color
Green
Amber
5G INDOOR ROUTER FG2000e USER GUIDE
Operation Meaning
Solid Strong 5G connection (3 – 5 bars)
Blinking Weak 5G connection (1 – 2 bars)
Solid Strong 4G connection (3 – 5 bars)
Blinking Weak 4G connection (1 – 2 bars)
Solid Internet is available only on Ethernet WAN
Blinking Factory reset
Solid Software update is in progress
Solid Router is booting up
Blinking No service, SIM error, or locked SIM card
Operation Meaning
Indicates Ethernet connection speed
Solid 1000 Mbps (Gigabit)
Blinking Data is being transferred
Off 10/100 Mbps
Indicates port status
Solid Port is being connected, but no data is being transferred
Off Port is being disconnected
