Add new VPN tunnel: Use this button to add a new VPN tunnel. The Add New VPN Tunnel Dialog
appears.
Add New VPN Tunnel: Step 1 out of 5
General Settings
• Start tunnel — Select whether to start the tunnel automatically upon start up or manually.
•
Enable tunnel —Check this box to enable the tunnel.
• Tunnel name — Enter a unique name to identify this VPN.
• Local identity — Enter a unique name to identify the local point of the tunnel.
• Remote identity — Enter a unique name to identify the remote point of the tunnel.
•
Local authentication — Select an authentication type from the drop-down list. You will be
prompted for further information based on your selection.
• Remote authentication — Select an authentication type from the drop-down list. You will be
prompted for further information based on your selection.
Add New VPN Tunnel: Step 2 out of 5
Local Network
• Local IP — Enter the WAN IP address of local device.
are able to reach from remote device (no NAT).
• Local subnet mask — Enter the subnet mask of the local device, for example: If your local IP is
192.168.0.100 and your subnet mask is 255.255.255.0 this should be 192.168.0.0/24.
This should mirror what the subnet displays in the local device, for example: 192.168.0.0 /
NOTE:
255.255.255.0.
example: If the Remote Subnet Mask is 192.168.1.0/24, the Local Subnet Mask might be
192.168.0.0/24. This is usually based off the DHCP settings of the devices.
Remote Network
•
Remote IP — Enter the WAN IP address of remote device.
you are able to reach from local device (no NAT).
•
Remote subnet mask — Enter the subnet mask of the remote device, for example: If your
remote IP is 192.168.1.100 and your subnet mask is 255.255.255.0 this should be
192.168.1.0/24.
example: 192.168.1.0 / 255.255.255.0.
from local, for example: If the Local Subnet Mask is 192.168.0.0/24, the Remote Subnet Mask
might be 192.168.1.0/24. This is usually based off the DHCP settings of the devices.
5G INDOOR ROUTER FG2000e USER GUIDE
The local device should be on a different subnet from remote, for
NOTE: This should mirror what the subnet displays in the local device, for
NOTE:
NOTE: This should be a static IP that you
NOTE: This should be a static IP that
The remote device should be on a different subnet
NOTE:
