Do NOT modify the plugs in any way. Do NOT use extension cords.
Depending on the model the electrical power supply must be either 115-volt or 230-volt
AC, 1 phase, 60 cycle. For 50hz systems the electrical power supply must be 240-volt,
1 phase, 50 cycle. The electrical power cannot vary more than plus or minus 4% or
damage may occur to the unit.
Plug the unit into the wall outlet, gently pull on the plug to make sure it is tight.
Fig. 1: Plug configurations
Required For:
Models D025/D050
-115VAC, 60Hz
-NEMA 5-15P
-NEMA 5-15R
Required For:
Models D088
-230VAC, 60Hz
-NEMA 6-15P
-NEMA 5-15R
Required For:
Models D200
-230VAC, 60Hz
-NEMA 6-20P
-NEMA 5-15R
28
