Technical Tips

Please connect the Y Cable carefully as above connecting
drawing otherwise it will cause you much inconvenience.
3. With the supplied video cable, connect to the converter's VIDEO OUT to
your TV or VCR video input.
PC to TV Converter - Multi Vision
Note:
OUT, RGB SCART and YCbCr OUT connector. If your TV or VCR support S-
VIDEO IN or RGB VIDEO IN or YCbCr input connector, we highly recommended
you to use it to get the best TV picture.
4. Connect one end of the supplied USB or PS/2 power cable to the DC IN
PC to TV Converter - Multi Vision
port on the
to your PC.
5. Power on your PC.
6. Power on the
7. Turn on your TV or VCR, and select the input from VIDEO IN, then you
can get the picture on TV.
The following are problems that might arise when using the PC to TV
converter, and possible solutions of them.
Q: How can I enhance the display quality?
A: You can usually lower the TV contrast and sharpness control at the best position,
you can get a very good picture. To have the best effect, lower the contrast control to
minimize the flicker effect.
also supports high quality S-
PC to TV Converter - Multi Vision
Please connect the Y.Cb.Cr to Y.Cb.Cr
cable as above connecting drawing.
and connect the other end
.
