- Page 1 3G SDI to HDMI Converter ID# 857 Operation Manual...
- Page 2 Introduction The SDI to HDMI converter allows SD-SDI, HD-SDI and 3G-SDI signals to be shown on HDMI/SDI displays while ensuring high bit rates of 2.970 Gbit/s to give you fast signal transmission without any loss. For professionals this means that it is now easier to distribute and extend your 3G SDI signal while giving you the ability to display your work on HDMI displays thanks to the built in HDMI converter.
- Page 3 Operation Controls and Functions Front Panel Power LED: This red LED will switch on when the device is connected with the power supply. 2. Video Lock LED: This green LED will turn on when both the input SDI source and the output HDMI display have sent and received a signal. 3.
- Page 4 3. DC 5V: Plug the 5V DC power supply into the unit and connect the adaptor to an AC outlet. The red LED will turn on when the power is on. Specifications SMPTE Standard 425M Level A & B, 424M, 292M, 259M-C SDI Transmission Rates 2.970 Gbit/s and 2.970/1.001 Gbit/s Frequency Bandwidth...
