- Page 1 HDMI to DVI-D Converter w/ SPDIF Digital Audio # 431 Operation Manual...
- Page 2 Introduction This converter box is designed to convert video and audio signal from HDMI source to DVI-D plus Coaxial audio outputs. The product allows you to connect the HDMI source to a display with DVI-D input meanwhile extract digital audio signal from the same source to an audio receiver. The HDMI converter box also does signal amplification and equalization for incoming TMDS data before re-transmitting them with optimal quality regardless of the incoming signal quality.
- Page 3 1. Power input: Plug the supplied 5V DC power supply into the unit and the LED will illuminate when the power is connected. 2. HDMI output: Connects the HDMI output connector of your source equipment. 3. Digital audio (SPDIF) input: Connects to the digital audio output of your source equipment.
- Page 4 B. HDMI Intput Pin Assignment Connection and Installation...
- Page 5 Specifications Input port: 1 x HDMI Output ports: 1 x DVI, 1 x SPDIF(Coaxial) Digital video output: DVI-I connector (RGB or YpbPr pass through) Digital audio output: Coaxial (S/PDIF) HDMI input: Compliant with HDMI 1.1 Operation frequency: Up to 165 MHz Input/Output resolutions: VGA@60/72/75/85Hz, SVGA@60/72/75/85Hz, XGA@60/70/75/85/87Hz, SXGA@60/75/85Hz,...
