Converters.TV 551 Operation Manual

Pal-ntsc-secam video to pal-ntsc video converter

Advertisement

Quick Links

PAL-NTSC-SECAM Video to
PAL-NTSC Video Converter
ID
# 551
Operation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the 551 and is the answer not in the manual?

Questions and answers

Summary of Contents for Converters.TV 551

  • Page 1 PAL-NTSC-SECAM Video to PAL-NTSC Video Converter # 551 Operation Manual...
  • Page 2 Introduction This Video system converter is designed to convert NTSC/PAL/SCAM input source to NTSC/PAL display. It support output formats switch for NTSC or PAL. The user can easily to install and use in NTSC/PAL display. Features Supports digital conversion from NTSC/PAL/SCAM to NTSC/PAL. To convert between 525 lines and 625 lines.
  • Page 3 Rear Panel Video input: Connected video source H. POS. Center: To adjust the display to right/left. DC 5V/1A: Power input. NTSC/PAL: Select the output signal. N,P stand for output signals of PAL and NTSC 3.58 respectively. Video output: Connected to video output display. Installation...
  • Page 4 Specifications Input System NTSC, PAL, SECAM – Output System NTSC 3.58, PAL – Input Port Video – Output Port Video – Sampling Frequency Y: 13.5MHz – R-Y: 6.75MHz B-Y: 6.75MHz Digital Code bit R: 8 bits – G: 8 bits B: 8 bits Line 525/625...
