SMC Networks VCH41 Series Instruction Manual page 4

Series
VCH40
Series
Stable responsiveness
Response time variation within ±2 ms
Collision-proof construction
between the iron cores keeps
equipment free of abrasion.
Construction with reduced
variation and improved
responsiveness when
switching off.
Improved durability by applying
a special surface treatment
to the sliding parts.
Unnecessary volume inside
the pilot chamber is reduced.
High speed response
with reduced variance
VCHC40
Series
Uses NSF-H1-certified
grease on the guide ring
(sliding part).
1
5.0 MPa Pilot Operated 2 Port Solenoid Valve
& Check Valve
VCH40/VCHC40
For Air
Service life: 10 million cycles
Use of shock absorbing rubber,
results in protection of the
pilot valve and electric parts.
Improved durability under a high
pressure environment is due to the
polyurethane elastomer poppet.
Improved durability under a high
pressure environment is due to the
polyurethane elastomer poppet.
