Applicable Cable O.d. Ø6 To; Ø6 To; Out) - SMC Networks VCH41 Series Instruction Manual

VCH400
Series
Dimensions
VCH410
62
50.5
G1/2
Applicable cable
O.D. ø6 to 12

2(OUT)

9
17
2 2 2
G1/4 x 7
Pilot EXH
41
ø17.5
3(EXH)
3 3 3
50
G1/2, 3/4: „70 G1: „80
16
1 1 1
2 x ø8.5
3 x G1/2 x 15
Mounting hole
3 x G3/4 x 16.3
3 x G1 x 19.1
1(IN)
