Revolution 25, 75, 150 Series HVLS Fans
INSTALLATION
4

Fan Clearance

Shown: Revolution 75, 150
Roof Surface
A
A
B
MOUNTING SURFACE
Mounting Surface
B
B 10 ft (3050 mm) MIN
A
10 ft (3050 mm) MIN
Floor
4
Mount the fan according to the fan clearance for your
fan model and diameter:
• Fans require open space above the blades for air
intake and maximum performance.
• Fan blades require safe clearance to operate.
Identify any potential obstructions the fan blades
could impact.


NOTE: The blades move upward during operation.
8
ROOF SURFACE
Installation/Service/Owner's Manual
A
MOUNTING SURFACE
3
B
ROOF SURFACE
A
ROOF SURFACE
MOUNTING SURFACE
B
FLOOR
10 ft (3050 mm) MIN
FINISH
CONFIDENTIAL
THIS DOCUMENT IS THE PROPERTY
A. Roof surface to mounting surface:
OF RITE-HITE® AFTERMARKET CORP.
SUBJECT MATTER HEREIN
IS CONFIDENTIAL.
•
Used to determine air intake.
DO NOT USE, REPRODUCE, COPY
OR DISCLOSE WITHOUT
FLOOR The bottom of the mounting surface is typically the lowest flat face of a beam, WRITTEN CONSENT OF
•
RITE-HITE® AFTERMARKET CORP.
© 2021 RITE-HITE®
open web joist angle, laminated beam, or purlin. ENGINEERED SOLUTIONS GROUP, INC.
3
B. Fan drop height:
Measured from the bottom of the mounting surface to the bottom of the fan.
C. Mounting surface to potential obstruction (maximum distance).
D. Blade tip at rest to potential obstruction (minimum distance).
E. Minimum clearance to potential obstruction:
12 in (310 mm)
F. Minimum clearance to floor:
10 ft (3050 mm)
G. Example of side view of truss.
H. Extension Tube
