RITE-HITE Revolution 25 Series Installation/Service/Owner's Manual page 6

®
Revolution 25, 75, 150 Series HVLS Fans
INSTALLATION
Preparation
Continued
Each fan assembly includes a NEMA plug on a 5 ft cord.
Before installing, ensure that a mating receptacle is
available in the ceiling near the installation location.
The type of receptacle required is dependent on the
ordered voltage:
Revolution 25 Series
Supply Voltage
Plug Type
Fan F.L.A.
Maximum number of fans recommended per branch circuit:
20A Circuit
Revolution 75 Series
Supply Voltage
Plug Type
Fan F.L.A.
Maximum number of fans recommended per branch circuit:
20A Circuit
30A Circuit
Revolution 150 Series
Supply Voltage
Plug Type
Fan F.L.A.
Maximum number of fans recommended per branch circuit:
20A Circuit
30A Circuit
6
Installation/Service/Owner's Manual
100-120V 1Φ 200-240V 1Φ
NEMA 5‑15 NEMA 6‑20
8.7
1
200-240V 1Φ 200-240V 3Φ
NEMA 6‑30 NEMA 15‑20
15.4
n/a
1
200-240V 1Φ 200-240V 3Φ
NEMA 6‑30 NEMA 15‑20
19.9
n/a
1
200-240V 3Φ
NEMA 15‑20
6.6 3.2
2 5
277V 1Φ
NEMA 7‑20
7.6 11.1
2 1
3 2
277V 1Φ
NEMA 7‑20
9.7 14.3
1 1
2 1
Rite‑Hite
277V 1Φ
NEMA 7‑20
4.8
3
400-480V 3Φ
NEMA 16‑20
3.6
4
6
400-480V 3Φ
NEMA 16‑20
4.5
3
5
Publication: AMEN00190 2021-09-24
®
