1.4 I/O Panel

1
14
15
No. Description
1
BIOS Flashback Button
2
2.5G LAN RJ-45 Port*
3
Microphone Input Jack**
4
Line Out Jack**
5
USB 3.2 Gen1 Type-A Ports
(USB32_56)
6
USB 3.2 Gen2 Type-A Ports
(USB32_78)
7
USB 3.2 Gen1 Type-A Port (USB32_4) 15
8
USB4 Type-C Port
3
2
4
13
12
11
No. Description
9
10
11
12
13
14
9
7
10
8
USB 3.2 Gen2 Type-A Port
(USB32_3)***
USB4 Type-C Port
Optical SPDIF Out Port
USB 3.2 Gen2 Type-A Ports
(USB32_12)****
HDMI Port
Antenna Ports
Clear CMOS Button
X670E Taichi
5
6
9
