  • Page 2 Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp...

  • Page 3: Table Of Contents

    Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Block Diagram 802.11ax Wi-Fi 6E Module and ASRock WiFi 2.4/5/6 GHz Antenna Wireless Dongle USB Bracket Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM)
  • Page 4 2.12 Onboard Headers and Connectors 2.13 Smart Switches 2.14 Dr. Debug 2.15 M.2 SSD Module Installation Guide (M2_1) 2.16 M.2 SSD Module Installation Guide (M2_2) 2.17 M.2 SSD Module Installation Guide (M2_3) 2.18 M.2 SSD Module Installation Guide (M2_4)

  • Page 5: Chapter 1 Introduction

    If you require technical support related to this mother- board, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 6: Specifications

    • Supports DDR5 non-ECC, un-buffered memory up to 7800+(OC)* • Max. capacity of system memory: 192GB • Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) Expansion CPU: Slot • 2 x PCIe 5.0 x16 Slots (PCIE1 and PCIE2), support x16 or x8/...
  • Page 7 X670E Taichi * Only the CPU's embedded graphics can be displayed through USB4 ports. If you want to display to a Type-C monitor, please use CPU models with embedded graphics. Audio • 5.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec) • WIMA Audio Capacitors (For Front Outputs)
  • Page 8 • 4 x SATA3 6.0 Gb/s Connectors ASMedia ASM1061: • 4 x SATA3 6.0 Gb/s Connectors** * Supports NVMe SSD as boot disks * Supports ASRock U.2 Kit ** If M2_2 is occupied by a SATA-type M.2 device, SATA3_A1 will be disabled.
  • Page 9 X670E Taichi RAID • Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices • Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices Connector • 1 x Power LED and Speaker Header • 1 x RGB LED Header* • 3 x Addressable LED Headers**...
  • Page 10 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 11: Motherboard Layout

    X670E Taichi 1.3 Motherboard Layout CHA_FAN1/WP CPU_FAN2/WP_3A CLRC BIOS CPU_FAN1 ATX12V1 ATX12V2 M2_WIFI_1 CT11 H D M I1 USB 3.2 Gen2 Top: CT10 T: USB32_1 RJ-45 B: USB32_2 TB_1 TB_2 CHA_FAN2/WP M2_2 CHA_FAN6 USB32_TC_1 BIOS PCIE1 X670 AUDIO CODEC PCIE2...
  • Page 12 No. Description 8 pin 12V Power Connector (ATX12V1) 8 pin 12V Power Connector (ATX12V2) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2) CPU/Water Pump Fan Connector (CPU_FAN2/WP_3A) Chassis/Water Pump Fan Connector (CHA_FAN1/WP) Addressable LED Header (ADDR_LED3) Addressable LED Header (ADDR_LED2) ATX Power Connector (ATXPWR1)

  • Page 13: I/O Panel

    X670E Taichi 1.4 I/O Panel No. Description No. Description BIOS Flashback Button USB 3.2 Gen2 Type-A Port 2.5G LAN RJ-45 Port* (USB32_3)*** Microphone Input Jack** USB4 Type-C Port Line Out Jack** Optical SPDIF Out Port USB 3.2 Gen1 Type-A Ports USB 3.2 Gen2 Type-A Ports...
  • Page 14 *There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port Activity / Link LED Speed LED Status Description Status Description No Link 10Mbps connection 100Mbps/1Gbps Blinking Data Activity...

  • Page 15: Block Diagram

    X670E Taichi 1.5 Block Diagram...

  • Page 16: 802.11Ax Wi-Fi 6E Module And Asrock Wifi 2.4/5/6 Ghz Antenna

    1.6 802.11ax Wi-Fi 6E Module and ASRock WiFi 2.4/5/6 GHz Antenna 802.11ax Wi-Fi 6E + BT Module This motherboard comes with an exclusive 802.11 a/b/g/n/ac/ax Wi-Fi 6E + BT module that offers support for 802.11 a/b/g/n/ac/ax Wi-Fi 6E connectivity standards and Bluetooth.

  • Page 17: Wireless Dongle Usb Bracket

    X670E Taichi 1.7 Wireless Dongle USB Bracket Installing the Wireless Dongle USB Bracket Step 1 Plug the Wireless Dongle USB Bracket into the USB 2.0 header on your motherboard. Step 2 Now you have two external USB 2.0 ports at hand.

  • Page 18: Chapter 2 Installation

    Chapter 2 Installation This is an EATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 19: Installing The Cpu

    X670E Taichi 2.1 Installing the CPU 1. Before you insert the 1718-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 20 Carefully place the CPU in as flat as possible. Do not drop it.
  • Page 21 X670E Taichi Make sure the CPU is aligned with the socket before locking it into place. Make sure the black cover plate is always in place until it pops off when closing the socket lever. Please save the cover if the processor is removed. The cover must be placed if you wish to...

  • Page 22: Installing The Cpu Fan And Heatsink

    2.2 Installing the CPU Fan and Heatsink After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other.
  • Page 23 X670E Taichi...
  • Page 24 Installing the CPU Cooler (Type 2)
  • Page 25 X670E Taichi...
  • Page 26 +12V *The illustrations shown here are for reference purposes only and may not exactly match the model you purchase.
  • Page 27 X670E Taichi Installing the CPU Cooler (Type 3)
  • Page 29 X670E Taichi...
  • Page 30 +12V Please note that only one cable should be used at a time in this step. If you select RGB_LED1, please install ASRock utility "ASRock Polychrome SYNC". If you select USB connector, please install AMD utility "SR3 Settings Software". *The illustrations shown here are for reference purposes only and may not exactly match...

  • Page 31: Installing Memory Modules (Dimm)

    X670E Taichi 2.3 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs.

  • Page 33: Connecting The Front Panel Header

    X670E Taichi 2.4 Connecting the Front Panel Header Front Panel Wires System Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 34: Installing The Motherboard

    2.5 Installing the Motherboard...

  • Page 35: Installing Sata Drives

    X670E Taichi 2.6 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 36 SATA Power Connector SATA Data Connector...

  • Page 37: Installing A Graphics Card

    X670E Taichi 2.7 Installing a Graphics Card CLICK!
  • Page 38 Expansion Slots (PCIe Slots) There are 2 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 39: Connecting Peripheral Devices

    X670E Taichi 2.8 Connecting Peripheral Devices...

  • Page 40: Connecting The Power Connectors

    2.9 Connecting the Power Connectors...

  • Page 41: Power On

    X670E Taichi 2.10 Power On...

  • Page 42: Jumpers Setup

    2.11 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRCMOS1) (see p.7, No. 25) CLRCMOS1 allows you to clear the data in CMOS.
  • Page 43 X670E Taichi 2.12 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header (9-pin PANEL1) (see p.7, No.
  • Page 44 Power LED and Speaker Header (7-pin SPK_PLED1) (see p.7, No. 19) Please connect the chassis power LED and the chassis speaker to this header. SPK_PLED1 SPEAKER DUMMY DUMMY PLED+ PLED+ PLED-...
  • Page 45 X670E Taichi Serial ATA3 Connectors Right Angle: (SATA3_1) (see p.7, No. 17)(Lower) (SATA3_2) (see p.7, No. 17)(Upper) (SATA3_3) (see p.7, No. 18)(Lower) (SATA3_4) (see p.7, No. 18)(Upper) (SATA3_A1) (see p.7, No. 15)(Lower) (SATA3_A2) (see p.7, No. 15)(Upper) (SATA3_A3) (see p.7, No. 16)(Lower) (SATA3_A4) (see p.7, No.
  • Page 46 USB 2.0 Headers (9-pin USB_1_2) (see p.7, No. 28) (9-pin USB_3_4) (see p.7, No. 27) There are two headers on this motherboard. Each USB 2.0 header can support two ports. USB_3_4 USB_PWR DUMMY USB_PWR USB_1_2 USB_PWR DUMMY USB_PWR...
  • Page 47 X670E Taichi USB 3.2 Gen1 Headers (19-pin USB32_9_10) (see p.7, No. 26) (19-pin USB32_11_12) (see p.7, No. 12) There are two headers on this motherboard. Each USB 3.2 Gen1 header can support two ports. USB32_11_12 Vbus Vbus Vbus IntA_PB_SSRX- IntA_PA_SSRX-...
  • Page 48 Front Panel Type C USB 3.2 Gen2x2 Header (20-pin USB32_TC_1) (see p.7, No. 13) There is one Front Panel Type C USB 3.2 Gen2x2 Header on this motherboard. This header is used for connecting a USB 3.2 Gen2x2 module for additional USB 3.2 Gen2x2 ports.
  • Page 49 X670E Taichi Front Panel Audio Header (9-pin HD_AUDIO1) (see p.7, No. 32) This header is for connecting audio devices to the front audio panel. HD_AUDIO1 MIC2_L MIC2_R OUT2_R J_SENSE OUT2_L OUT_RET MIC_RET PRESENCE# GN D High Definition Audio supports Jack Sensing, but the panel wire on the chassis must sup- port HDA to function correctly.
  • Page 50 Chassis/Water Pump Fan Connectors (4-pin CHA_FAN1/WP) (see p.7, No. 7) (4-pin CHA_FAN2/WP) (see p.7, No. 11) (4-pin CHA_FAN3/WP) (see p.7, No. 23) (4-pin CHA_FAN4/WP) (see p.7, No. 24) (4-pin CHA_FAN5/WP) (see p.7, No. 31) (4-pin CHA_FAN6/WP) (see p.7, No. 14) This motherboard provides six 4-Pin water cooling chassis fan connectors.
  • Page 51 X670E Taichi CPU Fan Connector (4-pin CPU_FAN1) (see p.7, No. 3) This motherboard provides a 4-Pin CPU fan (Quiet Fan) connector. If you plan to connect a 3-Pin CPU fan, please connect it to Pin 1-3. CPU_FAN1 +12V CPU_F AN_SPEED...
  • Page 52 ATX Power Connector (24-pin ATXPWR1) (see p.7, No. 10) This motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATXPWR1...
  • Page 53 X670E Taichi ATX 12V Power Connectors (8-pin ATX12V1) (see p.7, No. 1) (8-pin ATX12V2) (see p.7, No. 2) This motherboard provides two 8-pin ATX 12V power connectors. To use a 4-pin ATX power supply, please plug it along Pin 1 and Pin 5.
  • Page 54 RGB LED Header (4-pin RGB_LED1) (see p.7, No. 30) This RGB header is used to connect RGB LED extension cable which allow users to choose from various LED lighting effects. Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 55 X670E Taichi Addressable LED Headers (3-pin ADDR_LED1) (see p.7, No. 29) (3-pin ADDR_LED2) (see p.7, No. 9) (3-pin ADDR_LED3) (see p.7, No. 8) These headers are used to connect Addressable LED extension cables which allow users to choose from various LED lighting effects.
  • Page 56 1. Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged. 2. Before installing or removing your RGB LED cable, please power off your system and unplug the power cord from the power supply. Failure to do so may cause damages to motherboard components.
  • Page 57 X670E Taichi 2.13 Smart Switches The motherboard has four smart switches: Power Button, Reset Button, Clear CMOS Buttons and BIOS Flashback Button, allowing users to quickly turn on/off the system, reset the system, clear the CMOS values or flash the BIOS.
  • Page 58 Clear CMOS Button (CLRCMOS) (see p.9, No. 15) Clear CMOS Button allows users to quickly clear the CMOS values. CLRCMOS This function is workable only when you power off your computer and unplug the power supply.
  • Page 59 X670E Taichi BIOS Flashback Button (BIOS_FB) (see p.9, No. 1) BIOS Flashback Button allows users to flash the BIOS. BIOS_FB USB BIOS Flashback port...
  • Page 60 ASRock BIOS Flashback feature allows you to update BIOS without powering on the system, even without CPU. Before using the BIOS Flashback function, please suspend BitLocker and any encryption or security relying on the TPM. Make sure that you have already stored and backup-ed the recovery key.
  • Page 61 X670E Taichi 2.14 Dr. Debug Dr. Debug is used to provide code information, which makes troubleshooting even easier. Please see the diagrams below for reading the Dr. Debug codes. Code Description 0x10 PEI_CORE_STARTED 0x11 PEI_CAR_CPU_INIT 0x15 PEI_CAR_NB_INIT 0x19 PEI_CAR_SB_INIT 0x31...
  • Page 62 0x63 DXE_CPU_INIT 0x68 DXE_NB_HB_INIT 0x69 DXE_NB_INIT 0x6A DXE_NB_SMM_INIT 0x70 DXE_SB_INIT 0x71 DXE_SB_SMM_INIT 0x72 DXE_SB_DEVICES_INIT 0x78 DXE_ACPI_INIT 0x79 DXE_CSM_INIT 0x90 DXE_BDS_STARTED 0x91 DXE_BDS_CONNECT_DRIVERS 0x92 DXE_PCI_BUS_BEGIN 0x93 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT...
  • Page 63 X670E Taichi 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN 0x9B DXE_USB_RESET 0x9C DXE_USB_DETECT 0x9D DXE_USB_ENABLE 0xA0 DXE_IDE_BEGIN 0xA1 DXE_IDE_RESET 0xA2 DXE_IDE_DETECT 0xA3 DXE_IDE_ENABLE 0xA4 DXE_SCSI_BEGIN 0xA5 DXE_SCSI_RESET 0xA6 DXE_SCSI_DETECT 0xA7 DXE_SCSI_ENABLE 0xA8 DXE_SETUP_VERIFYING_PASSWORD 0xA9 DXE_SETUP_START 0xAB DXE_SETUP_INPUT_WAIT 0xAD DXE_READY_TO_BOOT 0xAE DXE_LEGACY_BOOT...
  • Page 64 0xAF DXE_EXIT_BOOT_SERVICES 0xB0 RT_SET_VIRTUAL_ADDRESS_MAP_BEGIN 0xB1 RT_SET_VIRTUAL_ADDRESS_MAP_END 0xB2 DXE_LEGACY_OPROM_INIT 0xB3 DXE_RESET_SYSTEM 0xB4 DXE_USB_HOTPLUG 0xB5 DXE_PCI_BUS_HOTPLUG 0xB6 DXE_NVRAM_CLEANUP 0xB7 DXE_CONFIGURATION_RESET 0xF0 PEI_RECOVERY_AUTO 0xF1 PEI_RECOVERY_USER 0xF2 PEI_RECOVERY_STARTED 0xF3 PEI_RECOVERY_CAPSULE_FOUND 0xF4 PEI_RECOVERY_CAPSULE_LOADED 0xE0 PEI_S3_STARTED 0xE1 PEI_S3_BOOT_SCRIPT 0xE2 PEI_S3_VIDEO_REPOST...
  • Page 65 X670E Taichi 0xE3 PEI_S3_OS_WAKE 0x50 PEI_MEMORY_INVALID_TYPE 0x53 PEI_MEMORY_NOT_DETECTED 0x55 PEI_MEMORY_NOT_INSTALLED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED 0x59 PEI_CPU_NO_MICROCODE 0x5A PEI_CPU_ERROR 0x5B PEI_RESET_NOT_AVAILABLE 0xD0 DXE_CPU_ERROR 0xD1 DXE_NB_ERROR 0xD2 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN...
  • Page 66 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR 0xDA DXE_BOOT_OPTION_FAILED 0xDB DXE_FLASH_UPDATE_FAILED 0xDC DXE_RESET_NOT_AVAILABLE 0xE8 PEI_MEMORY_S3_RESUME_FAILED 0xE9 PEI_S3_RESUME_PPI_NOT_FOUND 0xEA PEI_S3_BOOT_SCRIPT_ERROR 0xEB PEI_S3_OS_WAKE_ERROR...
  • Page 67 X670E Taichi 2.15 M.2 SSD Module Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Blazing M.2 Socket (M2_1, Key M) supports type 2280 PCIe Gen5x4 (128 Gb/s) mode.
  • Page 68 Step 3 Before installing a M.2 SSD module, please loosen the screws to remove the M.2 heatsink. *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD module. Step 4 Align and gently insert the M.2 SSD module into the M.2 slot.
  • Page 69 X670E Taichi Step 6 Tighten the screw with a screwdriver to secure the M.2 heatsink into place in the order shown. Tighten screw opposite the M.2 connector first (2), and then tighten the one next to the M.2 connector (3).
  • Page 70 Using Blazing M.2 Gen5 Fan Heatsink Blazing M.2 Gen5 Fan Heatsink is a M.2 SSD heatsink with fan specially designed for PCIe Gen5 SSD to achieve optimal heat dissipation. Follow the steps below to replace the pre- installed M.2 heatsink with Blazing M.2 Gen5 Fan Heatsink that comes with the package. Step 1 Prepare a M.2 SSD module and the screw.
  • Page 71 X670E Taichi Step 4 Tighten the screw that comes with the package with a screwdriver to secure the module into place. NUT2 NUT1 Step 5 Dimension: 144.58*36.7*46.9 mm Fan Speed: 7000 rpm Remove the protective films on the bottom side of Blazing M.2 Gen5 Fan Heatsink.
  • Page 72 2.16 M.2 SSD Module Installation Guide (M2_2) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_2, Key M) supports type 2230/2242/2260/2280/22110 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes. * If M2_2 is occupied by a SATA-type M.2 device, SATA3_A1 will be disabled.
  • Page 73 X670E Taichi Step 3 Before installing a M.2 SSD module, please loosen the screws to remove the M.2 heatsink. *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD module. Step 4 Prepare the M.2 standoff that comes...
  • Page 74 M.2 connector (3). *Please do not overtighten the screw as this might damage the module and M.2 heatsink. For the latest updates of M.2 SSD module support list, please visit our website for details: http://www.asrock.com...
  • Page 75 X670E Taichi 2.17 M.2 SSD Module Installation Guide (M2_3) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_3, Key M) supports type 2280 PCIe Gen4x4 (64 Gb/s) mode.
  • Page 76 Step 3 Before installing a M.2 SSD module, please loosen the screws to remove the M.2 heatsink. *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD module. Step 4 Align and gently insert the M.2 SSD module into the M.2 slot.
  • Page 77 X670E Taichi Step 6 Tighten the screws with a screwdriver to secure the M.2 heatsink into place in the order shown. Tighten screws opposite the M.2 connector first (2), and then tighten the ones next to the M.2 connector (3).
  • Page 78 2.18 M.2 SSD Module Installation Guide (M2_4) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_4, Key M) supports type 2280 PCIe Gen4x4 (64 Gb/s) mode. Installing the M.2 SSD Module Step 1 Prepare a M.2 SSD module and the...
  • Page 79 X670E Taichi Step 3 Before installing a M.2 SSD module, please loosen the screws to remove the M.2 heatsink. *Please remove the protective films on the bottom side of the M.2 heatsink before you install a M.2 SSD module. Step 4 Align and gently insert the M.2 SSD...
  • Page 80 M.2 connector (3). *Please do not overtighten the screw as this might damage the module and M.2 heatsink. For the latest updates of M.2 SSD module support list, please visit our website for details: http://www.asrock.com...
  • Page 81 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 82 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply)
  • Page 83 ASRock follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock product is in line with global environmental regulations. In addition, ASRock disclose the relevant information based on regulation requirements.
  • Page 84 Operations in the 5.15-5.35GHz band are restricted to indoor usage only. Radio transmit power per transceiver type Function Frequency Maximum Output Power (EIRP) 2400-2483.5 MHz 18.5 + / -1.5 dbm 5150-5250 MHz 21.5 + / -1.5 dbm 18.5 + / -1.5 dbm (no TPC) 5250-5350 MHz WiFi 21.5 + / -1.5 dbm (TPC)
