No. Description
1
8 pin 12V Power Connector (ATX12V1)
2
8 pin 12V Power Connector (ATX12V2)
3
CPU Fan Connector (CPU_FAN1)
4
2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)
5
2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2)
6
CPU/Water Pump Fan Connector (CPU_FAN2/WP_3A)
7
Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
8
Addressable LED Header (ADDR_LED3)
9
Addressable LED Header (ADDR_LED2)
10
ATX Power Connector (ATXPWR1)
11
Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
12
USB 3.2 Gen1 Header (USB32_11_12)
13
Front Panel Type C USB 3.2 Gen2x2 Header (USB32_TC_1)
14
Chassis/Water Pump Fan Connector (CHA_FAN6/WP)
15
SATA3 Connectors (SATA3_A2)(Upper), (SATA3_A1)(Lower)
16
SATA3 Connectors (SATA3_A4)(Upper), (SATA3_A3)(Lower)
17
SATA3 Connectors (SATA3_2)(Upper), (SATA3_1)(Lower)
18
SATA3 Connectors (SATA3_4)(Upper), (SATA3_3)(Lower)
19
Power LED and Speaker Header (SPK_PLED1)
20
System Panel Header (PANEL1)
21
Power Button (PWRBTN1)
22
Reset Button (RSTBTN1)
23
Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
24
Chassis/Water Pump Fan Connector (CHA_FAN4/WP)
25
Clear CMOS Jumper (CLRCMOS1)
26
USB 3.2 Gen1 Header (USB32_9_10)
27
USB 2.0 Header (USB_3_4)
28
USB 2.0 Header (USB_1_2)
29
Addressable LED Header (ADDR_LED1)
30
RGB LED Header (RGB_LED1)
31
Chassis/Water Pump Fan Connector (CHA_FAN5/WP)
32
Front Panel Audio Header (HD_AUDIO1)
8
