  • Page 2 Version 1.0 Published May 2024 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 AUSTRALIA ONLY Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage caused by our goods. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Chapter 2 Installation Installing the CPU Installing the CPU Cooler Installing Memory Modules (SO-DIMM) Jumpers Setup Onboard Headers and Connectors M.2 WiFi/BT Module Installation Guide M.2 SSD Module Installation Guide (M2_1) M.2 SSD Module Installation Guide (M2_2) Chapter 3 Auto Driver Installer Chapter 4 UEFI SETUP UTILITY...
  • Page 5 4.4.1 CPU Configuration 4.4.2 Onboard Devices Configuration 4.4.3 Storage Configuration 4.4.4 ACPI Configuration 4.6.5 USB Configuration 4.4.6 Trusted Computing 4.4.7 LVDS Control 4.4.8 AMD CBS 4.4.9 AMD PBS 4.4.10 AMD Overclocking Tools Hardware Health Event Monitoring Screen Security Screen Boot Screen Exit Screen...

  • Page 6: Chapter 1 Introduction

    X600TM-ITX Chapter 1 Introduction Thank you for purchasing X600TM-ITX motherboard. In this documentation, Chapter 1 and 2 contains the introduction of the motherboard and step-by-step installation guides. Chapter 3 contains the operation guide of the software and utilities. Chapter 4 contains the configuration guide of the BIOS setup.

  • Page 7: Specifications

    • Max. capacity of system memory: 96GB • Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules * Please refer to Memory Support List on ASRock’s website for more information. (http://www.asrock.com/) Expansion • 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module...
  • Page 8 X600TM-ITX • 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz (Rear DP2) * (Optional) 1 x D-Sub, supports max. resolution up to Full HD (1920x1200) 60Hz • 1 x LVDS, supports max. resolution up to Full HD (1920x1080)
  • Page 9 • 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* * Supports NVMe SSD as boot disks Connector * (Optional) 1 x Onboard TPM 2.0 (INFINEON SLB9672 or NU- VOTON NPCT750AADYX) • 1 x Chassis Intrusion Header • 1 x Panel Voltage Selection Header • 1 x Backlight Inverter Voltage Selection Header • 1 x FPD Brightness Header...
  • Page 10 X600TM-ITX Power • 1 x DC Jack (Supports 19V DC Power Adapters) Certifica- • FCC, CE tions • ErP/EuP ready (ErP/EuP ready power supply is required) Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 11: Motherboard Layout

    BKT_PWR1 USB2_1_2 BLT_VOL1 USB3_5_6 SATA_2 M2_1_CT1 RoHS SATAPWR1 DDR5_B1 M2_1_CT2 SATAPWR2 DDR5_A1 CPU_FAN1 NUT1 X600TM-ITX USB 3.2 Gen2 T: USB3_3 B: USB_TC_1 M.2 WiFi RJ-45 M.2 SSD USB 3.2 Gen1 T: USB3_1 B: USB3_2 Mic In Line out Audio CODEC...
  • Page 12 X600TM-ITX Back Side View M.2 SSD...
  • Page 13 No. Description 4 pin 19V Power Connector (ATX_PWR1) SATA Power Connector (SATAPWR2) SATA Power Connector (SATAPWR1) SATA3 Connector (SATA_1) SATA3 Connector (SATA_2) USB 3.2 Gen1 Header (USB3_5_6) Clear CMOS Jumper (CLRCMOS1) USB 2.0 Header (USB2_1_2) FPD Brightness Header (BLT_VOL1) Backlight Inverter Voltage Selection Header (BKT_PWR1) Panel Voltage Selection Header (PNL_PWR1) Panel On/Off Header (PANEL_SW1) LVDS Connector (LVDS1)

  • Page 14: I/O Panel

    X600TM-ITX 1.4 I/O Panel No. Description No. Description DC Jack** LAN RJ-45 Port* HDMI Port (HDMI1) USB 3.2 Gen1 Type-A Ports Display Port (DP2) (USB3_12) USB 3.2 Gen2 Type-A Port (USB3_3) Microphone (Pink) USB 3.2 Gen2 Type-C Port (USB_TC_1) Line out (Lime) *There are two LEDs on each LAN port.

  • Page 15: Chapter 2 Installation

    Chapter 2 Installation This is a Thin Mini-ITX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 16: Installing The Cpu

    X600TM-ITX 2.1 Installing the CPU 1. Before you insert the 1718-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 17 Carefully place the CPU in as flat as possible. Do not drop it.
  • Page 18 X600TM-ITX Make sure the CPU is aligned with the socket before locking it into place. Make sure the black cover plate is always in place until it pops off when closing the socket lever. Please save the cover if the processor is removed. The cover must be placed if you wish to...

  • Page 19: Installing The Cpu Cooler

    2.2 Installing the CPU Cooler After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other.

  • Page 20: Installing Memory Modules (So-Dimm)

    X600TM-ITX 2.3 Installing Memory Modules (SO-DIMM) This motherboard provides two 260-pin DDR5 (Double Data Rate 5) SO-DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 SO-DIMM pairs.
  • Page 21 1. Carefully insert the SO-DIMM memory modules into the slot at a 30-degree angle. 2. Push down until the modules snap into place.

  • Page 22: Jumpers Setup

    X600TM-ITX 2.4 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRCMOS1) (see p.6, No.
  • Page 23 Backlight Inverter Voltage 1-2 : +19V Selection Header 2-3 : +12V (3-pin BKT_PWR1) (see p.6, No. 10) Panel Voltage Selection 1-2 : +3V Header 2-3 : +5V (5-pin PNL_PWR1) 4-5 : +12V (see p.6, No. 11) Warning: If selected Backlight Power or Panel Power is higher than panel's spec, it may damage the panel.

  • Page 24: Onboard Headers And Connectors

    X600TM-ITX 2.5 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header...
  • Page 25 Serial ATA3 Connectors These two SATA3 SATA_1 SATA_2 (SATA_1: connectors support SATA see p.6, No. 4) data cable for internal (SATA_2: storage devices with up to see p.6, No. 5) 6.0 Gb/s data transfer rate. SATA Power Connectors Please connect SATA (SATAPWR1: +12V power cables.
  • Page 26 X600TM-ITX 1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must sup- port HDA to function correctly. Please follow the instructions in our manual and chassis manual to install your system. 2. If you use an AC’97 audio panel, please install it to the front panel audio header by the steps below: A.
  • Page 27 FPD Brightness Header 1: BKLT_PWR (8-pin BLT_VOL1) 2: BKLT_PWR (see p.6, No. 9) 3: BKLT_EN 4: BKLT_PWM 5: GND 6: GND 7: Brightness_Up 8: Brightness_Down LVDS Panel Connector Signal Name Signal Name (30-pin LVDS1) LCD_VDD CLK1P LCD_VDD (see p.6, No. 13) LCD_VDD CLK2N CLK2P...
  • Page 28 X600TM-ITX Panel On/Off Header This header can be used to connect a switch that turns on/ (2-pin PANEL_SW1) PWR_DOWN off the LVDS panel display’s (see p.6, No. 12) backlight. Digital MIC Header 1: +5V (5-pin DMIC1) 2: No pin (see p.6, No. 17)

  • Page 29: Wifi/Bt Module Installation Guide

    2.6 M.2 WiFi/BT Module Installation Guide The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT module. Installing the WiFi/BT module Step 1 Prepare a type 2230 WiFi/BT module and the screw.
  • Page 30 X600TM-ITX Step 4 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module.
  • Page 31 2.7 M.2 SSD Module Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode. Installing the M.2 SSD Module Step 1 Prepare a M.2 SSD module and the...
  • Page 32 X600TM-ITX Step 3 Peel off the yellow protective film on the nut A. Prepare the M.2 standoff that comes with the package, and hand tighten it into the nut A. Skip Step 3 if your M.2 SSD module is Type 2280.
  • Page 33 M.2 SSD Module Support List (M2_2) M2_PCIE: Vendor Capacity ADATA 256GB ADATA ASX8200 Pro-256G ADATA 512GB ADATA SX8200 PRO-512GB (ASX8200PNP) ADATA 512GB ADATA ASX7000NPC-512GT-C (XPG SX7000) Apacer 240GB Apacer AP240GZ280-240G Crucial CRUCIAL P1-1T Crucial 500GB CRUCIAL P1-500G INTEL 16GB Intel Optane Memory 16GB (MEMPEK1W016GA)(NVMe) INTEL 32GB Intel Optane Memory 32GB (MEMPEK1J032GA)(NVMe)
  • Page 34 X600TM-ITX 2.5" HDD: Vendor Capacity TOSHIBA TOSHIBA-MQ02ABD100H-MLC-NAND8G+HD1T-1T SEAGATE 500GB SEAGATE-ST500LM021-3Y/P-500G SEAGATE SEAGATE-FIRECUDA-LX015-ST1000LX015-5Y/P- 7mm-1T-W/8G 750GB WD-BLACK-WD7500BPKX-750G WD-RED-WD10JFCX-INTELLIPOWER-1T WD-BLUE-WD10SPZX-00Z10T0-1T-3Y-02 HGST HGST-HTS721010A9E630-1TB 2.5" SSD: Vendor Capacity KINGSTON 120GB KINGSTON-V300-SV300S37A-120G KINGSTON KINGSTON-HYPERX-FURY-RGB- 120GB SHFR200/240G-240G-W/RGB CABLEx1 KINGSTON 240GB KINGSTON-HYPERX-SAVAGE-SHSS37A/240G TOSHIBA 128GB TOSHIBA-Q300 PRO-HDTS412AZSTA-128G TOSHIBA 120GB...
  • Page 35 Vendor Capacity UMAX 240GB UMAX-S330-HDUM330SSD240G-240G-3Y PIONEER 120GB PIONEER-APS-SL3N-APS-SL3N-120-120G-3Y ANACONDA 240GB ANACONDA-TS SERIES-TS240201803718-240G-3Y KLEVV 240GB KLEVV-NEO-N500-D240GAA-N500-240G-3Y TCELL 240GB TCELL-TT650-240G-3Y Liteon 240GB LITE-ON-MU3-PH6-PH6-CE240-L2-240G-3Y V-Color 240GB V-COLOR-VSS100-VSS100-240G-FO-240G-3Y HIKVISION 480GB HIKVISION-C100-HS-SSD-C100-480G-3Y SAMSUNG SAMSUNG-860EVO-MZ-76E250BW-MZ7LH- 250GB 250HAHQ-250G TEAM TEAM GROUP-T-FORCE-DELTA RGB- 250GB T253TR250G3C313-5V-250G-3Y...

  • Page 36: Ssd Module Installation Guide (M2_1)

    X600TM-ITX 2.8 M.2 SSD Module Installation Guide (M2_2) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_2, Key M) supports type 2280 PCIe Gen4x4 (64 Gb/s) mode.
  • Page 37 M.2 SSD Module Support List (M2_3) M2_SATA: Vendor Capacity ADATA 512GB ADATA ASU800NS38-512GT-C Crucial 240GB Crucial-CT240M500SSD4-240GB Crucial 250GB Crucial-CT250MX500SSD4-250G ezlink 120GB ezlink P51B-80-120GB LITEON 256GB LITEON LJH-256V2G-256GB (2260) SanDisk 128GB SanDisk X400-SD8SN8U-128G SanDisk 128GB Sandisk Z400s-SD8SNAT-128G-1122 Transcend 64GB Transcend TS64GMTS400-64GB (2242) Transcend 256GB Transcend TS256GMTS800-256GB...

  • Page 38: Chapter 3 Auto Driver Installer

    X600TM-ITX Chapter 3 Auto Driver Installer After you install the Windows OS and boot into the system, a notification will pop up to help you to install and update required drivers.

  • Page 39: Chapter 4 Uefi Setup Utility

    Chapter 4 UEFI SETUP UTILITY 4.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. You may run the UEFI SETUP UTILITY by pressing <F2> or <Del> right after you power on the computer, otherwise, the Power-On-Self-Test (POST) will continue with its test routines.

  • Page 40: Navigation Keys

    X600TM-ITX 4.1.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter>...

  • Page 41: Main Screen

    4.2 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview.

  • Page 42: Oc Tweaker Screen

    Performance Preset Use the ASRock Performance Preset. Platform Thermal Throttle Limit (TjMax) Allows the user to decrease the maximum allowed processor temperature (celsius).
  • Page 43 DRAM Frequency If [Auto] is selected, the motherboard will detect the memory module(s) inserted and assign the appropriate frequency automatically. Setting DRAM Frequency can adjust DRAM Timing. DRAM Profile Configuration Load EXPO/XMP settings to overclock the DDR5 memory and perform beyond standard specifications.

  • Page 44: Advanced Screen

    X600TM-ITX 4.4 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Onboard Devices Configuration, Storage Configuration, ACPI Configuration, USB Configuration, Trusted Computing, LVDS Control, AMD CBS, AMD PBS and AMD Overclocking. Setting wrong values in this section may cause the system to malfunction.
  • Page 45 Full HD UEFI When [Auto] is selected, the resolution will be set to 1920 x 1080 if the monitor supports Full HD resolution. If the monitor does not support Full HD resolution, then the resolution will be set to 1024 x 768. When [Disable] is selected, the resolution will be set to 1024 x 768 directly.

  • Page 46: Cpu Configuration

    X600TM-ITX 4.4.1 CPU Configuration PSS Support Use this to enable or disable the generation of ACPI_PPC, _PSS, and _PCT objects. NX Mode Use this to enable or disable NX mode. SMT Mode This item can be used to disable symmetric multithreading. To re-enable SMT, a power cycle is needed after selecting [Auto].

  • Page 47: Onboard Devices Configuration

    4.4.2 Onboard Devices Configuration Onboard HD Audio Enable/disable onboard HD audio. Onboard LAN Enable or disable the onboard network interface controller WIFI Card Enable/disable the WIFI Card.

  • Page 48: Storage Configuration

    X600TM-ITX 4.4.3 Storage Configuration Third Party SATA 3 Controller Enable or disable the third party SATA3 controller. Third Party SATA3 Hot Plug Enable or disable the third party SATA3 controller.

  • Page 49: Acpi Configuration

    4.4.4 ACPI Configuration Suspend to RAM It is recommended to select auto for ACPI S3 power saving. Configuration options: [Disabled] [Auto] Restore on AC/Power Loss Allows you to select the power state after a power failure. [Power Off] Select this item and the power will remain off when the power recovers. [Power On] Select this item and the system will start to boot up when the power recovers.
  • Page 50 X600TM-ITX USB Devices Power On [Enabled] Select this item to allow the system to be waked up by a USB device and enable wake on LAN. [Disabled] Select this item to disallow the system to be waked up by a USB device and disable wake on LAN.

  • Page 51: Usb Configuration

    4.6.5 USB Configuration XHCI Hand-off This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. USB Mass Storage Driver Support This item allows you to enable or disable USB Mass Storage Driver Support.

  • Page 52: Trusted Computing

    X600TM-ITX 4.4.6 Trusted Computing NOTE: Options vary depending on the version of your connected TPM module. Security Device Support Use this item to enable or disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available.
  • Page 53 TPM2.0 UEFI Spec Version Use this item to select the TCG2 spec. version supported. The optional settings: [TCG_1_2]; [TCG_2]. [TCG_1_2]: compatible mode for Win8/Win10. [TCG_2]: for TCG2 newer spec. compatible mode for Win10 Physical Presence Spec version Select this item to tell OS to support PPI spec version 1.2 or 1.3. Please note that some HCK tests might not support version 1.3.

  • Page 54: Lvds Control

    X600TM-ITX 4.4.7 LVDS Control Active LVDS Enable or disable LVDS Control. LVDS Panel Type Selection Select the appropriate LVDS panel resolution.

  • Page 55: Amd Cbs

    4.4.8 AMD CBS The AMD CBS menu accesses AMD specific features.

  • Page 56: Amd Pbs

    X600TM-ITX 4.4.9 AMD PBS The AMD PBS menu accesses AMD specific features.

  • Page 57: Amd Overclocking

    4.4.10 AMD Overclocking The AMD Overclocking menu accesses options for configuring CPU frequency and voltage.

  • Page 58: Tools

    X600TM-ITX 4.5 Tools SSD Secure Erase Tool Use this tool to securely erase SSD. This tool only lists the SSDs that support the Secure Erase function. NVME Sanitization Tool After you Sanitize SSD, all user data will be permanently destroyed on the SSD and cannot be recovered.

  • Page 59: Hardware Health Event Monitoring Screen

    4.6 Hardware Health Event Monitoring Screen This section allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed and voltage. CPU Fan 1 Setting Select a fan mode for CPU Fan 1, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.

  • Page 60: Security Screen

    X600TM-ITX 4.7 Security Screen In this section you may set or change the supervisor/user password for the system. You may also clear the user password. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 61: Boot Screen

    4.8 Boot Screen This section displays the available devices on your system for you to configure the boot settings and the boot priority. Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. Launch PXE OpROM Policy Select UEFI only to run those that support UEFI option ROM only.
  • Page 62 X600TM-ITX Full Screen Logo Enable to display the boot logo or disable to show normal POST messages. Fast Boot Fast Boot minimizes your computer's boot time. In fast mode you may not boot from an USB storage device.

  • Page 63: Exit Screen

    4.9 Exit Screen Save Changes and Exit When you select this option the following message, “Save configuration changes and exit setup?” will pop out. Select [OK] to save changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option the following message, “Discard changes and exit setup?”...
  • Page 64 DECLARATION OF CONFORMITY Per FCC Part 2 Section 2.1077(a) Responsible Party Name: ASRock Incorporation Address: 13848 Magnolia Ave, Chino, CA91710 Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product Product Name : Motherboard X600TM-ITX Model Number : Conforms to the following speci cations:...
  • Page 65 EU Declaration of Conformity For the following equipment: Motherboard (Product Name) X600TM-ITX (Model Designation / Trade Name) EMC Directive – 2014/30/EU EN 55032: 2015 / A11: 2020, EN 55035: 2017 / A11: 2020 EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013...
  • Page 66 EU Declaration of Conformity Product: Product Motherboard Model X600TM-ITX Authorized Representative (UK-GB): Name: Gary Tsui Address: Bijsterhuizen 11-11, 6546 AR Nijmegen,The Netherlands Contact person: Gary Tsui This declaration is issued under the sole responsibility of the mentioned Manufacturer. The subject equipment under declaration is in conformity with the UK-GB Regulation(s) below: e Electromagnetic Compatibility Regulations 2016 (S.I.
