Rear Panel
I/O
Storage
4
• 7 x USB 3.2 Gen1 (3 Rear, 4 Front)
• 4 x USB 2.0 (Front)
* All USB ports support ESD Protection
• 2 x Antenna Ports
• 1 x HDMI Port
• 1 x Optical SPDIF Out Port
• 2 x USB4 Type-C Ports (40 Gb/s)*
• 5 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (ReDriver)
(USB32_12 are Lightning Gaming Ports. USB32_3 supports
Ultra USB Power.)
• 3 x USB 3.2 Gen1 Ports
• 1 x RJ-45 LAN Port
• 1 x Clear CMOS Button
• 1 x BIOS Flashback Button
• 1 x Line Out Jack (Gold Audio Jack)
• 1 x Microphone Input Jack (Gold Audio Jack)
* Supports USB PD 3.0 up to 9V@3A (27W) / 5V@3A (15W)
charging
CPU:
• 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280
PCIe Gen5x4 (128 Gb/s) mode*
Chipset:
• 1 x Hyper M.2 Socket (M2_2, Key M), supports type
2230/2242/2260/2280/22110 SATA3 6.0 Gb/s & PCIe Gen4x4
(64 Gb/s) modes*
• 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280
PCIe Gen4x4 (64 Gb/s) mode*
• 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2280
PCIe Gen4x4 (64 Gb/s) mode*
• 4 x SATA3 6.0 Gb/s Connectors
ASMedia ASM1061:
• 4 x SATA3 6.0 Gb/s Connectors**
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
** If M2_2 is occupied by a SATA-type M.2 device, SATA3_A1
will be disabled.
