For the latest updates of M.2 SSD module support list, please visit our website for details:
http://www.asrock.com
1
3
Step 6
Tighten the screw with a screwdriver
to secure the M.2 heatsink into place
in the order shown. Tighten screw
opposite the M.2 connector first (2),
and then tighten the one next to the
M.2 connector (3).
*Please do not overtighten the screw
as this might damage the module
and M.2 heatsink.
X670E Taichi
65
