USB 3.2 Gen1 Headers
(19-pin USB32_9_10) (see p.7, No. 26)
(19-pin USB32_11_12) (see p.7, No. 12)
There are two headers on this motherboard. Each USB 3.2 Gen1 header can
support two ports.
USB32_9_10
IntA_P_D+
IntA_P_D-
GND
IntA_P_SSTX+
1
GND
IntA_P_D-
IntA_P_D+
ID
IntA_P_SSTX-
GND
IntA_P_SSRX+
IntA_P_SSRX-
Vbus
Vbus
IntA_P_SSRX-
IntA_P_SSRX+
GND
IntA_P_SSTX-
IntA_P_SSTX+
USB32_11_12
Vbus Vbus
Vbus IntA_PB_SSRX-
IntA_PA_SSRX- IntA_PB_SSRX+
IntA_PA_SSRX+ GND
GND IntA_PB_SSTX-
IntA_PA_SSTX-
IntA_PB_SSTX+
IntA_PA_SSTX+
GND
GND IntA_PB_D-
IntA_PA_D- IntA_PB_D+
IntA_PA_D+ Dummy
1
