Bose ControlSpace ESP-88C Service Manual page 90

Noise
ATS2 Settings
Item
Frequency
Amplitude
B/W
Filter
Test Limits
Item
Level
Perform this test on channels 1 through 8.
5-3-2.Gain +36dB (Perform this test if using the 4x4 Series II card)
ESP Settings: Set all channel gains to = 36dB.
(Command on COM = ^BA{1/2}{L/R}36^C)
AMPL(1kHz)
ATS2 Settings
Item
Frequency
Amplitude
B/W
Filter
Test Limits
Item
Level
Noise
ATS2 Settings
Item
Frequency
Amplitude
B/W
Filter
Test Limits
Item
Level
TEST PROCEDURES
Setting
--
Off
22HZ / 22KHz LPF
"A" Weighting
Upper limit
-77dBu
Setting
1kHz
-20.00dBu
<10HZ / FS/2
None
Upper limit
+5.5dBu
Setting
--
Off
22HZ / 22KHz LPF
"A" Weighting
Upper limit
-77dBu
