Bose ControlSpace ESP-88C Service Manual page 50

Reference
Designator
C139 10uF, ELEC, 16V, 40C, 20%
C140 0.1uF, 0603, Y5V, 50V, 20%
C141 0.1uF, 0603, Y5V, 50V, 20%
C142 0.1uF, 0603, Y5V, 50V, 20%
C143 0.1uF, 0603, Y5V, 50V, 20%
C144 0.1uF, 0603, Y5V, 50V, 20%
C145 0.1uF, 0603, Y5V, 50V, 20%
C146 0.1uF, 0603, Y5V, 50V, 20%
C147 0.1uF, 0603, Y5V, 50V, 20%
C148 10uF, ELEC, 16V, 40C, 20%
C149 0.1uF, 0603, Y5V, 50V, 20%
C150 0.1uF, 0603, Y5V, 50V, 20%
C151 0.1uF, 0603, Y5V, 50V, 20%
C152 0.1uF, 0603, Y5V, 50V, 20%
C153 0.1uF, 0603, Y5V, 50V, 20%
C154 0.1uF, 0603, Y5V, 50V, 20%
C155 0.1uF, 0603, Y5V, 50V, 20%
C156 0.1uF, 0603, Y5V, 50V, 20%
C157 10uF, ELEC, 16V, 40C, 20%
C158 10uF, ELEC, 16V, 40C, 20%
C159 0.1uF, 0603, Y5V, 50V, 20%
C160 0.1uF, 0603, Y5V, 50V, 20%
C161 0.1uF, 0603, Y5V, 50V, 20%
C162 0.1uF, 0603, Y5V, 50V, 20%
C163 0.1uF, 0603, Y5V, 50V, 20%
C164 0.1uF, 0603, Y5V, 50V, 20%
C165 0.1uF, 0603, Y5V, 50V, 20%
C166 0.1uF, 0603, Y5V, 50V, 20%
C167 0.1uF, 0603, Y5V, 50V, 20%
C168 10uF, ELEC, 16V, 40C, 20%
C169 47pF, 0603, 50V, NPO, 55C, 5%
C170 47pF, 0603, 50V, NPO, 55C, 5%
C171 47pF, 0603, 50V, NPO, 55C, 5%
C172 0.1uF, 0603, Y5V, 50V, 20%
C173 0.1uF, 0603, Y5V, 50V, 20%
C174 0.1uF, 0603, Y5V, 50V, 20%
C175 0.1uF, 0603, Y5V, 50V, 20%
C176 47pF, 0603, 50V, NPO, 55C, 5%
C200 10uF, ELEC, 16V, 40C, 20%
C201 10uF, ELEC, 16V, 40C, 20%
C202 0.1uF, 0603, Y5V, 50V, 20%
C203 10uF, ELEC, 16V, 40C, 20%
C204 10uF, ELEC, 16V, 40C, 20%
C205 0.1uF, 0603, Y5V, 50V, 20%
C206 0.1uF, 0603, Y5V, 50V, 20%
C207 0.1uF, 0603, Y5V, 50V, 20%
C208 0.1uF, 0603, Y5V, 50V, 20%
C209 0.1uF, 0603, Y5V, 50V, 20%
C210 0.1uF, 0603, Y5V, 50V, 20%
ELECTRICAL PART LIST
ESP-88 Digital Signal Processor (DSP) PCB Assembly
Capacitors (continued)
Description Vendor Vendor Part Number
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
Samsung CL10C470JBNC
Samsung CL10C470JBNC
Samsung CL10C470JBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10C470JBNC
NICHICON UZT1C100MCR1GB
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
50
Note
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
