Bose ControlSpace ESP-88C Service Manual page 53

Reference
Designator
C456 0.047uF, 0603, X7R, 50V, 10%
C457 0.1uF, 0603, Y5V, 50V, 20%
C458 0.1uF, 0603, Y5V, 50V, 20%
C459 0.1uF, 0603, Y5V, 50V, 20%
C460 0.1uF, 0603, Y5V, 50V, 20%
C461 0.1uF, 0603, Y5V, 50V, 20%
C462 0.1uF, 0603, Y5V, 50V, 20%
C463 0.1uF, 0603, Y5V, 50V, 20%
C464 0.1uF, 0603, Y5V, 50V, 20%
C465 0.1uF, 0603, Y5V, 50V, 20%
C466 0.1uF, 0603, Y5V, 50V, 20%
C467 0.1uF, 0603, Y5V, 50V, 20%
C468 10uF, ELEC, 16V, 40C, 20%
C469 0.1uF, 0603, Y5V, 50V, 20%
C470 0.1uF, 0603, Y5V, 50V, 20%
C471 0.1uF, 0603, Y5V, 50V, 20%
C472 0.1uF, 0603, Y5V, 50V, 20%
C473 0.1uF, 0603, Y5V, 50V, 20%
C474 0.1uF, 0603, Y5V, 50V, 20%
C478 10uF, ELEC, 16V, 40C, 20%
C479 10uF, ELEC, 16V, 40C, 20%
C480 0.1uF, 0603, Y5V, 50V, 20%
C481 0.1uF, 0603, Y5V, 50V, 20%
C482 10uF, ELEC, 16V, 40C, 20%
C483 10uF, ELEC, 16V, 40C, 20%
C484 0.1uF, 0603, Y5V, 50V, 20%
C485 0.1uF, 0603, Y5V, 50V, 20%
C486 10uF, ELEC, 16V, 40C, 20%
C487 10uF, ELEC, 16V, 40C, 20%
C488 0.1uF, 0603, Y5V, 50V, 20%
C489 0.1uF, 0603, Y5V, 50V, 20%
C490 10uF, ELEC, 16V, 40C, 20%
C492 0.1uF, 0603, Y5V, 50V, 20%
C493 100uF, ELEC, 16V, 40C, 20%
C493 100uF, ELEC, 16V, 55C, 20%
C494 0.1uF, 0603, Y5V, 50V, 20%
C495 0.047uF, 0603, X7R, 50V, 10%
C496 0.047uF, 0603, X7R, 50V, 10%
C497 470uF, TANT, 4V, 55C, 20%
C498 100uF, ELEC, 16V, 40C, 20%
C498 100uF, ELEC, 16V, 55C, 20%
C499 0.1uF, 0603, Y5V, 50V, 20%
C500 0.1uF, 0603, Y5V, 50V, 20%
C501 0.1uF, 0603, Y5V, 50V, 20%
C502 0.1uF, 0603, Y5V, 50V, 20%
C503 0.1uF, 0603, Y5V, 50V, 20%
C504 0.1uF, 0603, Y5V, 50V, 20%
C505 0.1uF, 0603, Y5V, 50V, 20%
C506 0.1uF, 0603, Y5V, 50V, 20%
ELECTRICAL PART LIST
ESP-88 Digital Signal Processor (DSP) PCB Assembly
Capacitors (continued)
Description Vendor Vendor Part Number
Samsung CL10B471KBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
NICHICON UWX1C101MCR1GB
NICHICON UWT1C101MCR1GB
Samsung CL10F104ZBNC
Samsung CL10B473KBNC
Samsung CL10B102KBNC
NICHICON F930G477MNC
NICHICON UWX1C101MCR1GB
NICHICON UWT1C101MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
53
Note
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
