Esp-88C Chassis 4X4 Series Ii Pcb Assembly - Bose ControlSpace ESP-88C Service Manual

Reference Description
Designator
R100 100k
R101 100 Ohm
R102 100 Ohm
R103 100k
R104 OPEN
R105 6.8k
R106 6.8k
R107 OPEN
R108 6.8k
R109 6.8k
R110 1.3k
R111 OPEN
R112 5.1k
R113 OPEN
R114 OPEN
R115 82 Ohm
R116 OPEN
R117 68 Ohm
R118 OPEN
R119 OPEN
R120 1.3k
R121 OPEN
R122 5.1k
R123 OPEN
R124 OPEN
R125 82 Ohm
R126 OPEN
R127 68 Ohm
R128 560 Ohm
R129 240 Ohm
R131 680 Ohm
R132 680 Ohm
R133 680 Ohm
R134 680 Ohm
R135 680 Ohm
R136 680 Ohm
R137 680 Ohm
R138 680 Ohm
R139 560 Ohm
R140 240 Ohm
R141 39k
R142 39k
R143 39k
R144 10k
R145 10k
R146 6.8k
ELECTRICAL PART LIST

ESP-88C Chassis 4x4 Series II PCB Assembly

Resistors
Vendor Part Number
RK73H1JTD100kF
RK73H1JTD100RF
RK73H1JTD100RF
RK73H1JTD100kF
NOT USED
RK73H1JTD6.8KF
RK73H1JTD6.8KF
NOT USED
RK73H1JTD6.8KF
RK73H1JTD6.8KF
RK73H1JTD1.3KF
NOT USED
RK73H1JTD5.1KF
NOT USED
NOT USED
RK73H1JTD82RF
NOT USED
RK73H1JTD68RF
NOT USED
NOT USED
RK73H1JTD1.3KF
NOT USED
RK73H1JTD5.1KF
NOT USED
NOT USED
RK73H1JTD82RF
NOT USED
RK73H1JTD68RF
RK73H1JTD560RF
RK73H1JTD240RF
RK73H1JTD680RF
RK73H1JTD680RF
RK73H1JTD680RF
RK73H1JTD680RF
RK73H1JTD680RF
RK73H1JTD680RF
RK73H1JTD680RF
RK73H1JTD680RF
RK73H1JTD560RF
RK73H1JTD240RF
RK73H1JTD39KF
RK73H1JTD39KF
RK73H1JTD39KF
RK73H1JTD10KF
RK73H1JTD10KF
RK73H1JTD6.8KF
27
Vendor Name
KOA
KOA
KOA
KOA
NOT USED
KOA
KOA
NOT USED
KOA
KOA
KOA
NOT USED
KOA
NOT USED
NOT USED
KOA
NOT USED
KOA
NOT USED
NOT USED
KOA
NOT USED
KOA
NOT USED
NOT USED
KOA
NOT USED
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
Note
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
