Bose ControlSpace ESP-88C Service Manual page 42

Reference Description
Designator
C612 0.1uF
C613 0.1uF
C614 0.1uF
C615 0.1uF
C616 0.1uF
C617 0.1uF
C618 0.1uF
C700 0.1uF
C701 0.1uF
C702 0.1uF
C703 10uF, 16V
C704 0.1uF
C705 0.1uF
C706 10uF, 16V
C707 10uF, 16V
C708 0.1uF
C709 10uF, 16V
C710 0.1uF
C711 12pF
C712 12pF
C713 0.1uF
C714 0.1uF
C715 10uF, 16V
C716 0.1uF
C717 0.1uF
C718 0.1uF
C719 0.1uF
C720 47pF
C721 47pF
C722 47pF
C723 47pF
Reference Description
Designator
L600 NFM39R12C223
L601 BK2125HM102
L602 BK2125HM102
L603 NFM39R12C223
L604 BK2125HM102
L605 BK2125HM102
L606 BK2125HM102
L607 BK2125HM102
L608 NFM39R12C223
L609 BK2125HM102
L610 BK2125HM102
L611 NFM39R12C223
ELECTRICAL PART LIST
ESP-88C Chassis 4x4 Series II PCB Assembly
Capacitors (continued)
Vendor Part Number
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
MVK16VC10MD55
GRM188F11E104ZA01D
GRM188F11E104ZA01D
MVK16VC10MD55
MVK16VC10MD55
GRM188F11E104ZA01D
MVK16VC10MD55
GRM188F11E104ZA01D
P-GRM39CH120J-50
P-GRM39CH120J-50
GRM188F11E104ZA01D
GRM188F11E104ZA01D
MVK16VC10MD55
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM39CH470JZ01D
Inductors
Vendor Part Number
NFM39R12C223
BK2125HM102
BK2125HM102
NFM39R12C223
BK2125HM102
BK2125HM102
BK2125HM102
BK2125HM102
NFM39R12C223
BK2125HM102
BK2125HM102
NFM39R12C223
42
Vendor Name
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
NICHIKEMI
MURATA
MURATA
NICHIKEMI
NICHIKEMI
MURATA
NICHIKEMI
MURATA
MURATA
MURATA
MURATA
MURATA
NICHIKEMI
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
Vendor Name
MURATA
Taiyoyuden
Taiyoyuden
MURATA
Taiyoyuden
Taiyoyuden
Taiyoyuden
Taiyoyuden
MURATA
Taiyoyuden
Taiyoyuden
MURATA
Note
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
Note
4
4
4
4
4
4
4
4
4
4
4
4
