Bose ControlSpace ESP-88C Service Manual page 51

Reference
Designator
C211 0.1uF, 0603, Y5V, 50V, 20%
C212 0.1uF, 0603, Y5V, 50V, 20%
C213 0.1uF, 0603, Y5V, 50V, 20%
C214 0.1uF, 0603, Y5V, 50V, 20%
C215 0.1uF, 0603, Y5V, 50V, 20%
C216 0.1uF, 0603, Y5V, 50V, 20%
C217 0.1uF, 0603, Y5V, 50V, 20%
C218 0.1uF, 0603, Y5V, 50V, 20%
C219 0.1uF, 0603, Y5V, 50V, 20%
C220 0.1uF, 0603, Y5V, 50V, 20%
C221 0.1uF, 0603, Y5V, 50V, 20%
C222 0.1uF, 0603, Y5V, 50V, 20%
C223 0.1uF, 0603, Y5V, 50V, 20%
C224 0.1uF, 0603, Y5V, 50V, 20%
C225 0.1uF, 0603, Y5V, 50V, 20%
C226 0.1uF, 0603, Y5V, 50V, 20%
C227 0.1uF, 0603, Y5V, 50V, 20%
C228 0.1uF, 0603, Y5V, 50V, 20%
C229 0.1uF, 0603, Y5V, 50V, 20%
C230 0.1uF, 0603, Y5V, 50V, 20%
C231 0.1uF, 0603, Y5V, 50V, 20%
C232 0.1uF, 0603, Y5V, 50V, 20%
C233 0.1uF, 0603, Y5V, 50V, 20%
C234 0.1uF, 0603, Y5V, 50V, 20%
C235 0.1uF, 0603, Y5V, 50V, 20%
C236 47pF, 0603, 50V, NPO, 55C, 5%
C300 22pF, 0603, 50V, NPO, 55C, 5%
C301 0.1uF, 0603, Y5V, 50V, 20%
C302 0.1uF, 0603, Y5V, 50V, 20%
C303 0.1uF, 0603, Y5V, 50V, 20%
C304 0.1uF, 0603, Y5V, 50V, 20%
C305 0.1uF, 0603, Y5V, 50V, 20%
C306 0.1uF, 0603, Y5V, 50V, 20%
C307 0.1uF, 0603, Y5V, 50V, 20%
C308 0.1uF, 0603, Y5V, 50V, 20%
C309 0.1uF, 0603, Y5V, 50V, 20%
C310 22pF, 0603, 50V, NPO, 55C, 5%
C311 22pF, 0603, 50V, NPO, 55C, 5%
C312 22pF, 0603, 50V, NPO, 55C, 5%
C313 0.1uF, 0603, Y5V, 50V, 20%
C314 0.1uF, 0603, Y5V, 50V, 20%
C315 10uF, ELEC, 16V, 40C, 20%
C316 10uF, ELEC, 16V, 40C, 20%
C317 0.1uF, 0603, Y5V, 50V, 20%
C318 0.1uF, 0603, Y5V, 50V, 20%
C319 0.1uF, 0603, Y5V, 50V, 20%
C320 0.1uF, 0603, Y5V, 50V, 20%
C321 10uF, ELEC, 16V, 40C, 20%
C322 0.1uF, 0603, Y5V, 50V, 20%
ELECTRICAL PART LIST
ESP-88 Digital Signal Processor (DSP) PCB Assembly
Capacitors (continued)
Description Vendor Vendor Part Number
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10C470JBNC
Samsung CL10C220JBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10C220JBNC
Samsung CL10C220JBNC
Samsung CL10C220JBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
