Bose ControlSpace ESP-88C Service Manual page 32

Reference Description
Designator
R382 2.2k
R403 10k
R404 4.7k
R405 OPEN
R406 OPEN
R407 OPEN
R408 OPEN
R409 15k
R410 15k
R411 15k
R412 15k
R413 2.2k
R414 1k
R415 1k
R416 2.2k
R417 47 Ohm
R418 47 Ohm
R419 10 Ohm
R420 10 Ohm
R421 10k
R422 10k
R423 10k
R424 6.8k
R425 10k
R426 6.8k
R427 6.8k
R428 10k
R429 6.8k
R430 10k
R431 4.7k
R432 4.7k
R433 33 Ohm
R434 33 Ohm
R435 2.2k
R436 10k
R437 1.8k
R438 10k
R439 2.2k
R440 1.8k
R441 1.5k
R442 1.5k
R443 2.2k
R444 1k
R445 1k
R446 2.2k
R447 10k
ELECTRICAL PART LIST
ESP-88C Chassis 4x4 Series II PCB Assembly
Resistors (continued)
Vendor Part Number
RK73H1JTD2.2KF
RK73H1JTD10KF
RK73H1JTD4.7KF
NOT USED
NOT USED
NOT USED
NOT USED
RK73H1JTD15KF
RK73H1JTD15KF
RK73H1JTD15KF
RK73H1JTD15KF
RK73H1JTD2.2KF
RK73H1JTD1KF
RK73H1JTD1KF
RK73H1JTD2.2KF
RK73H1JTD47RF
RK73H1JTD47RF
RK73H1JTD10RF
RK73H1JTD10RF
RK73H1JTD10KF
RK73H1JTD10KF
RK73H1JTD10KF
RK73H1JTD6.8KF
RK73H1JTD10KF
RK73H1JTD6.8KF
RK73H1JTD6.8KF
RK73H1JTD10KF
RK73H1JTD6.8KF
RK73H1JTD10KF
RK73H1JTD4.7KF
RK73H1JTD4.7KF
RK73H1JTD33RF
RK73H1JTD33RF
RK73H1JTD2.2KF
RK73H1JTD10KF
RK73H1JTD1.8KF
RK73H1JTD10KF
RK73H1JTD2.2KF
RK73H1JTD1.8KF
RK73H1JTD1.5KF
RK73H1JTD1.5KF
RK73H1JTD2.2KF
RK73H1JTD1KF
RK73H1JTD1KF
RK73H1JTD2.2KF
RK73H1JTD10KF
32
Vendor Name
KOA
KOA
KOA
NOT USED
NOT USED
NOT USED
NOT USED
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
RHOM
RHOM
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
Note
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
