Bose ControlSpace ESP-88C Service Manual page 36

Reference Description
Designator
C100 0.1uF
C101 10uF, 16V
C102 0.1uF
C103 0.1uF
C104 10uF, 16V
C105 0.1uF
C106 47uF, 16V
C107 47uF, 16V
C108 0.1uF
C109 0.1uF
C110 0.1uF
C111 0.1uF
C112 0.1uF
C113 0.1uF
C114 0.1uF
C115 0.1uF
C116 0.1uF
C117 0.1uF
C118 47uF, 16V
C119 47uF, 16V
C120 47uF, 16V
C121 47uF, 16V
C122 10uF, 16V
C123 10uF, 16V
C124 10uF, 16V
C125 10uF, 16V
C126 10uF, 16V, BP
C127 100pF
C128 100pF
C129 100pF
C130 10uF, 16V, BP
C131 47pF
C132 47pF
C133 47pF
C134 47pF
C135 47pF
C136 47pF
C137 0.1uF
C138 0.1uF
C139 47pF
C140 47pF
C141 47pF
C142 47pF
C143 47pF
C144 47pF
C145 10uF, 16V, BP
ELECTRICAL PART LIST
ESP-88C Chassis 4x4 Series II PCB Assembly
Capacitors
Vendor Part Number
GRM188F11E104ZA01D
MVK16VC10MD55
GRM188F11E104ZA01D
GRM188F11E104ZA01D
MVK16VC10MD55
GRM188F11E104ZA01D
MVK16VC47MF55
MVK16VC47MF55
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
MVK16VC47MF55
MVK16VC47MF55
MVK16VC47MF55
MVK16VC47MF55
MVK16VC10MD55
MVK16VC10MD55
MVK16VC10MD55
MVK16VC10MD55
RVB16V100M-R
GRM39CH101JZ01D
GRM39CH101JZ01D
GRM39CH101JZ01D
RVB16V100M-R
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM39CH470JZ01D
GRM39CH470JZ01D
RVB16V100M-R
36
Vendor Name
MURATA
NICHIKEMI
MURATA
MURATA
NICHIKEMI
MURATA
NICHIKEMI
NICHIKEMI
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
NICHIKEMI
NICHIKEMI
NICHIKEMI
NICHIKEMI
NICHIKEMI
NICHIKEMI
NICHIKEMI
NICHIKEMI
ELNA
MURATA
MURATA
MURATA
ELNA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
ELNA
Note
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
