Bose ControlSpace ESP-88C Service Manual page 80

4-4. Fundamental Setting of ATS-2
4-4-1.Analog Generator Setting.
Item
Wave form
Frequency
Out puts
Track
Amplitude
Configuration
Z-Out(Ohms)
4-4-2.Analog Input Setting.
Item
Source
Peak Monitor
Auto Range
DC
TEST PROCEDURES
Setting
Sine(Normal)
1kHz
A/B-ON
Track-A
+4.00dBu
Bal XLR
40
Setting
XLR-Bal (Both A/B
Channel)
Set the units "dBu"
Check
No Check
4-4-3.Analyzer Setting.
Item
Instrument
Input
Level
Frequency
Range
Measurement
Function
Function
Range
Detect
Band width
BP/BR filter
frequency
Filter
80
Setting
Audio Analyzer
Analog
Set the units "dBu"
Set the units "kHz"
Check both
THD+N Ratio
Set the units "%"
Check both
Auto-RMS
22Hz~20kHz LPF
Sweep Track
"A" weighting
