- Page 1 Operation & Service Manual Model: 02A1040-0111 10 Ton Single Stage Jack 11/2004 - AA - Rev. 04 Includes Illustrated Parts Lists Tronair, Inc. 1740 Eber Road Holland, Ohio 43528-9794 • Telephone: (419) 866-6301 800-426-6301 Fax: (419) 867-0634 Web Site: www.tronair.com E-mail: sales@tronair.com...
-
Page 3: Table Of Contents
Model: 02A1040-0111 10 Ton Single Stage Jack TABLE OF CONTENTS PAGE Description ................................1 Usage................................1 Specifications..............................1 Assembly Instructions............................1 General Instruction ..........................1 Pre-Use Checks ............................1 Operating Instructions............................2 Jack Instructions............................2 Maintenance ..............................4 General..............................4 Servicing Jack ............................5 Removing And Servicing Pump.......................5 Jack Function Load Test .........................5 Pneumatic Pump .............................5... - Page 4 Model: 02A1040-0111 10 Ton Single Stage Jack REVISION DATE CHANGE MADE 12/2003 pg 6 Replacement Parts List: modified "Not Shown" part number 11/2004 pg 2 5.1 added warning and illustrations 11/2004 - AA - Rev. 04...
-
Page 5: Description
Model: 02A1040-0111 10 Ton Single Stage Jack This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc., it suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur. -
Page 6: Operating Instructions
Model: 02A1040-0111 10 Ton Single Stage Jack OPERATING INSTRUCTIONS The user should be familiar with the following statements prior to using the jack(s): CAUTION! 1. NEVER put hands between the aircraft and the jack pad; as after aircraft has been lowered, struts may have hung up. - Page 7 Model: 02A1040-0111 10 Ton Single Stage Jack JACK INSTRUCTIONS (continued) RAM PROTECTION RING CORRECT PIN PLACEMENT MECHANICAL EXTENSION LOCKING PIN WASHER AND WASHER GROOVE LOCKING PIN AREAS TO BE FREE OF INDENTATIONS RAM PROTECTION RING BALL LOCK INCORRECT PIN INCORRECT PIN...
-
Page 8: Maintenance
Model: 02A1040-0111 10 Ton Single Stage Jack JACK INSTRUCTIONS (continued) WARNING! The ram locknuts are user operated safety devices. Failure to utilize these locknuts may result in personal injury or death. To Lower Aircraft: Lower all jacks simultaneously. If ram locking nut(s) is tight, raise jack slightly to release nut(s). -
Page 9: Servicing Jack
Model: 02A1040-0111 10 Ton Single Stage Jack SERVICING JACK (continued) To Re-assemble Jack: Re-assemble in reverse order of above. NOTE: Torque four (4) socket head cap screws (Item 39) to 44 ft-lbs. Spray inside diameter of cylinder and outside diameter of ram (Items 1 & 42) with DoALL RPM, LPS or equivalent water repellent that will not harm the BUNA "N"... -
Page 10: Trouble Shooting
Model: 02A1040-0111 10 Ton Single Stage Jack TROUBLE SHOOTING AM WILL NOT RISE OR RISES ERRATICALLY ROBABLE AUSE ORRECTIVE CTION High pressure leaks (at joint, plugs or tubing) Re-tighten or repair Pump rapidly to dislodge; Leaky discharge check valve Or repair pump... - Page 11 Model: 02A1040-0111 10 Ton Single Stage Jack Parts List When ordering replacement parts/kits, please specify Model, Serial Number & color (if applicable) of your product. Reference Illustrations on Pages 9 - 11. REPLACEMENT PARTS ITEM PART NUMBER DESCRIPTION 2 ....H-1009-01 ........Handle, Hydraulic Pump..........1 5 ....H-1128-02 ........
- Page 12 Model: 02A1040-0111 10 Ton Single Stage Jack Parts List When ordering replacement parts/kits, please specify Model, Serial Number & color (if applicable) of your product. Reference Illustrations on Pages 9 - 11. REPLACEMENT KITS ITEM PART NUMBER DESCRIPTION K-2788 Kit, Reservoir Replacement; consists of: 16 ....N-2412-04 ........
- Page 13 Model: 02A1040-0111 10 Ton Single Stage Jack Parts List Illustrations 11/2004 - AA - Rev. 04 - 9 -...
- Page 14 Model: 02A1040-0111 10 Ton Single Stage Jack Parts List Illustrations 11/2004 - AA - Rev. 04 - 10 -...
- Page 15 Model: 02A1040-0111 10 Ton Single Stage Jack Parts List Illustrations 11/2004 - AA - Rev. 04 - 11 -...
- Page 17 APPENDIX I HC-1752 2,500 psi Hand Pump Parts List...
- Page 19 Model: HC-1752 2,500 psi Hand Pump Illustrated Parts List 08/2001 – Rev. OR Tronair, Inc. 1740 Eber Road Holland, Ohio 43528-9794 • Telephone: (419) 866-6301 800-426-6301 Fax: (419) 867-0634 Web Site: www.tronair.com E-mail: sales@tronair.com...
- Page 21 HC-1752 2,500 Hand Pump Parts List • This pump is compatible with MIL-H-5606 / MIL-H-83282 Hydraulic Fluids only. Reference Parts List Illustration on Page 3. REPLACEMENT PARTS ITEMPART NUMBER DESCRIPTION 3 ....5M1-000-001 ........Body, Pump ..............1 12 ....506-000 ..........Half, Flange ..............4 25 ....518-000 ..........
- Page 22 HC-1752 2,500 Hand Pump Parts List Reference Parts List Illustration on Page 3. REPLACEMENT KITS ITEMPART NUMBER DESCRIPTION K-1778 Kit, Piston/Cylinder Replacement; consists of: 15 ................Piston................1 16 ................Tube ................1 20 ................Retainer, Wiper ...............1 24 ................Assembly, Valve Body (Includes Items 7, 10, 24, 26) ..1 K-1906 Kit, Piston/Seal Replacement;...
- Page 23 HC-1752 2,500 Hand Pump Parts List Illustration WARNING! Item 2 is a preset relief valve. Do not disassemble this valve. Replacement parts are available as a preset relief valve assembly. 08/2001 – Rev. OR - 3 -...
-
Page 25: Appendix Ii
APPENDIX II Haskel MLP-20/46D Technical Specifications & Performance Data & Drawings 28550... -
Page 31: Appendix Iii Msds
APPENDIX III MSDS Hydraulic Fluid (MIL-H-5606)
